检索增强生成（RAG）技术详解

用户查询 → 检索相关文档 → 生成增强回答 → 返回结果
                ↓
          外部知识库

┌─────────────────────────────────────────────────────────────┐
│                    RAG系统架构                              │
├─────────────────────────────────────────────────────────────┤
│                                                             │
│  ┌──────────┐    ┌──────────┐    ┌──────────┐            │
│  │   文档   │ -> │  向量化  │ -> │ 向量数据库 │            │
│  │  预处理  │    │  (Embed) │    │   (DB)   │            │
│  └──────────┘    └──────────┘    └──────────┘            │
│                                                │           │
│                                                ↓           │
│  ┌──────────┐    ┌──────────┐    ┌──────────┐            │
│  │ 用户查询 │ -> │ 查询编码 │ -> │  相似度  │            │
│  └──────────┘    └──────────┘    │  检索    │            │
│                                  └──────────┘            │
│                                        │                  │
│                                        ↓                  │
│  ┌──────────────────────────────────────────────────┐    │
│  │              LLM生成模块                          │    │
│  │   查询 + 检索文档 → 增强提示 → 生成回答           │    │
│  └──────────────────────────────────────────────────┘    │
│                                                             │
└─────────────────────────────────────────────────────────────┘

similarity = cos(θ) = (A·B) / (||A|| × ||B||)

distance = ||A - B|| = √Σ(Ai - Bi)²

similarity = A·B = ΣAi × Bi

# RAG检索增强生成实践代码
import torch
import numpy as np
from typing import List, Dict, Optional, Tuple
import chromadb
from chromadb.config import Settings
from sentence_transformers import SentenceTransformer
import openai
from dataclasses import dataclass
from abc import ABC, abstractmethod
import re
import json
from tqdm import tqdm
import matplotlib.pyplot as plt
import pandas as pd

# ==================== 配置 ====================
OPENAI_API_KEY = "your-api-key-here"  # 替换为实际API密钥
openai.api_key = OPENAI_API_KEY

device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
print(f"使用设备: {device}")

# ==================== 文档处理器 ====================
class DocumentSplitter(ABC):
    """文档切分器基类"""

    @abstractmethod
    def split(self, text: str) -> List[str]:
        pass

class CharacterSplitter(DocumentSplitter):
    """固定字符数切分器"""

    def __init__(self, chunk_size: int = 500, overlap: int = 50):
        self.chunk_size = chunk_size
        self.overlap = overlap

    def split(self, text: str) -> List[str]:
        chunks = []
        start = 0

        while start < len(text):
            end = start + self.chunk_size
            chunk = text[start:end]
            chunks.append(chunk)
            start = end - self.overlap

        return [c for c in chunks if len(c.strip()) > 0]

class SemanticSplitter(DocumentSplitter):
    """语义切分器（基于段落和句子）"""

    def __init__(self, max_chunk_size: int = 1000, min_chunk_size: int = 200):
        self.max_chunk_size = max_chunk_size
        self.min_chunk_size = min_chunk_size

    def split(self, text: str) -> List[str]:
        # 按段落分割
        paragraphs = re.split(r'\n\s*\n', text)

        chunks = []
        current_chunk = ""

        for para in paragraphs:
            if len(current_chunk) + len(para) <= self.max_chunk_size:
                current_chunk += para + "\n\n"
            else:
                if len(current_chunk) >= self.min_chunk_size:
                    chunks.append(current_chunk.strip())
                current_chunk = para + "\n\n"

        if len(current_chunk) >= self.min_chunk_size:
            chunks.append(current_chunk.strip())

        return chunks

class RecursiveSplitter(DocumentSplitter):
    """递归切分器（多级切分）"""

    def __init__(self, separators: List[str] = None, chunk_size: int = 1000):
        self.separators = separators or ["\n\n", "\n", "。", ".", " ", ""]
        self.chunk_size = chunk_size

    def split(self, text: str) -> List[str]:
        return self._recursive_split(text, self.separators)

    def _recursive_split(self, text: str, separators: List[str]) -> List[str]:
        if len(text) <= self.chunk_size:
            return [text]

        if not separators:
            return [text[i:i+self.chunk_size]
                   for i in range(0, len(text), self.chunk_size)]

        separator = separators[0]
        parts = text.split(separator)

        chunks = []
        current_chunk = ""

        for part in parts:
            if len(current_chunk) + len(part) <= self.chunk_size:
                current_chunk += part + separator
            else:
                if current_chunk:
                    chunks.append(current_chunk.strip())
                if len(part) > self.chunk_size:
                    # 递归使用下一个分隔符
                    chunks.extend(self._recursive_split(part, separators[1:]))
                else:
                    current_chunk = part + separator

        if current_chunk:
            chunks.append(current_chunk.strip())

        return chunks

# ==================== 嵌入模型 ====================
class EmbeddingModel(ABC):
    """嵌入模型基类"""

    @abstractmethod
    def encode(self, texts: List[str]) -> np.ndarray:
        pass

class SentenceTransformerEmbedding(EmbeddingModel):
    """SentenceTransformer嵌入模型"""

    def __init__(self, model_name: str = "sentence-transformers/all-MiniLM-L6-v2"):
        self.model = SentenceTransformer(model_name, device=device)
        self.dimension = self.model.get_sentence_embedding_dimension()

    def encode(self, texts: List[str]) -> np.ndarray:
        return self.model.encode(texts, show_progress_bar=False)

class OpenAIEmbedding(EmbeddingModel):
    """OpenAI嵌入模型"""

    def __init__(self, model: str = "text-embedding-ada-002"):
        self.model = model
        self.dimension = 1536

    def encode(self, texts: List[str]) -> np.ndarray:
        embeddings = []
        for text in texts:
            response = openai.Embedding.create(
                input=text,
                model=self.model
            )
            embeddings.append(response['data'][0]['embedding'])
        return np.array(embeddings)

# ==================== 向量数据库 ====================
class VectorStore:
    """向量存储接口"""

    def __init__(self, embedding_model: EmbeddingModel):
        self.embedding_model = embedding_model
        self.chroma_client = chromadb.PersistentClient(
            path="./chroma_db"
        )
        self.collection = None

    def create_collection(self, name: str):
        """创建集合"""
        self.collection = self.chroma_client.get_or_create_collection(
            name=name,
            metadata={"hnsw:space": "cosine"}
        )

    def add_documents(self, documents: List[Dict[str, str]]):
        """添加文档到向量库"""
        texts = [doc['text'] for doc in documents]
        embeddings = self.embedding_model.encode(texts)

        ids = [f"doc_{i}" for i in range(len(documents))]
        metadatas = [{k: v for k, v in doc.items() if k != 'text'}
                     for doc in documents]

        self.collection.add(
            embeddings=embeddings.tolist(),
            documents=texts,
            metadatas=metadatas,
            ids=ids
        )

    def search(
        self,
        query: str,
        n_results: int = 5,
        filters: Optional[Dict] = None
    ) -> List[Dict]:
        """搜索相关文档"""
        query_embedding = self.embedding_model.encode([query])[0]

        results = self.collection.query(
            query_embeddings=[query_embedding.tolist()],
            n_results=n_results,
            where=filters
        )

        return [
            {
                'text': doc,
                'metadata': meta,
                'distance': dist
            }
            for doc, meta, dist in zip(
                results['documents'][0],
                results['metadatas'][0],
                results['distances'][0]
            )
        ]

    def delete_collection(self):
        """删除集合"""
        if self.collection:
            self.chroma_client.delete_collection(self.collection.name)

# ==================== RAG系统 ====================
class RAGSystem:
    """完整的RAG系统"""

    def __init__(
        self,
        embedding_model: EmbeddingModel,
        collection_name: str = "rag_knowledge_base"
    ):
        self.embedding_model = embedding_model
        self.vector_store = VectorStore(embedding_model)
        self.vector_store.create_collection(collection_name)
        self.splitter = SemanticSplitter()

    def ingest_documents(
        self,
        documents: List[str],
        metadatas: Optional[List[Dict]] = None
    ):
        """摄取文档到知识库"""
        all_chunks = []
        chunk_id = 0

        for i, doc in enumerate(tqdm(documents, desc="处理文档")):
            chunks = self.splitter.split(doc)

            for chunk in chunks:
                doc_data = {'text': chunk}

                if metadatas and i < len(metadatas):
                    doc_data.update(metadatas[i])

                doc_data['chunk_id'] = chunk_id
                doc_data['source_doc_id'] = i

                all_chunks.append(doc_data)
                chunk_id += 1

        print(f"切分完成：共{len(documents)}个文档 -> {len(all_chunks)}个块")

        # 添加到向量库
        self.vector_store.add_documents(all_chunks)

        print(f"文档已添加到知识库")

    def query(
        self,
        question: str,
        top_k: int = 3,
        filters: Optional[Dict] = None
    ) -> Dict:
        """查询RAG系统"""

        # 检索相关文档
        retrieved_docs = self.vector_store.search(
            query=question,
            n_results=top_k,
            filters=filters
        )

        # 构建增强提示
        context = "\n\n".join([
            f"[文档片段 {i+1}]\n{doc['text']}"
            for i, doc in enumerate(retrieved_docs)
        ])

        prompt = f"""基于以下参考文档回答问题。如果文档中没有相关信息，请明确说明。

参考文档：
{context}

问题：{question}

回答："""

        return {
            'prompt': prompt,
            'retrieved_docs': retrieved_docs,
            'context': context
        }

    def answer(
        self,
        question: str,
        top_k: int = 3,
        model: str = "gpt-3.5-turbo"
    ) -> Dict:
        """生成完整回答"""

        # 获取增强提示
        rag_result = self.query(question, top_k)

        # 调用LLM生成回答
        try:
            response = openai.ChatCompletion.create(
                model=model,
                messages=[
                    {"role": "system", "content": "你是一个有帮助的AI助手。"},
                    {"role": "user", "content": rag_result['prompt']}
                ],
                temperature=0.7,
                max_tokens=1000
            )

            answer = response.choices[0].message.content

            return {
                'question': question,
                'answer': answer,
                'sources': rag_result['retrieved_docs']
            }

        except Exception as e:
            return {
                'question': question,
                'answer': f"生成回答时出错: {str(e)}",
                'sources': rag_result['retrieved_docs']
            }

# ==================== 高级RAG技术 ====================
class HybridRAG(RAGSystem):
    """混合检索RAG（向量+关键词）"""

    def __init__(
        self,
        embedding_model: EmbeddingModel,
        collection_name: str = "hybrid_rag"
    ):
        super().__init__(embedding_model, collection_name)
        self.keyword_index = {}  # 简化的关键词索引

    def build_keyword_index(self, documents: List[str]):
        """构建关键词索引"""
        from collections import defaultdict
        import jieba  # 中文分词

        for i, doc in enumerate(documents):
            words = jieba.cut(doc)
            for word in words:
                if len(word) > 1:  # 忽略单字
                    if word not in self.keyword_index:
                        self.keyword_index[word] = []
                    self.keyword_index[word].append(i)

    def keyword_search(self, query: str, top_k: int = 5) -> List[int]:
        """关键词搜索"""
        import jieba
        words = jieba.cut(query)

        doc_scores = defaultdict(int)
        for word in words:
            if word in self.keyword_index:
                for doc_id in self.keyword_index[word]:
                    doc_scores[doc_id] += 1

        sorted_docs = sorted(doc_scores.items(), key=lambda x: -x[1])
        return [doc_id for doc_id, _ in sorted_docs[:top_k]]

    def query(self, question: str, top_k: int = 3, alpha: float = 0.5):
        """混合检索（结合向量和关键词）"""
        # 向量检索
        vector_results = self.vector_store.search(question, n_results=top_k * 2)

        # 关键词检索
        keyword_doc_ids = self.keyword_search(question, top_k=top_k * 2)

        # 融合结果
        fused_scores = {}

        for i, doc in enumerate(vector_results):
            doc_id = doc['metadata'].get('source_doc_id', i)
            fused_scores[doc_id] = fused_scores.get(doc_id, 0) + alpha * (1 - i / top_k)

        for i, doc_id in enumerate(keyword_doc_ids):
            fused_scores[doc_id] = fused_scores.get(doc_id, 0) + (1 - alpha) * (1 - i / top_k)

        # 排序
        sorted_docs = sorted(fused_scores.items(), key=lambda x: -x[1])
        top_doc_ids = [doc_id for doc_id, _ in sorted_docs[:top_k]]

        # 获取文档内容
        final_docs = [vector_results[i] for i in range(min(top_k, len(vector_results)))]

        return {
            'prompt': self._build_prompt(question, final_docs),
            'retrieved_docs': final_docs,
            'fusion_scores': fused_scores
        }

class AdaptiveRAG(RAGSystem):
    """自适应RAG（根据查询复杂度调整检索策略）"""

    def __init__(self, embedding_model: EmbeddingModel):
        super().__init__(embedding_model, "adaptive_rag")

        # 简单的查询复杂度分类器
        from sentence_transformers import util
        self.complexity_model = embedding_model

    def estimate_complexity(self, query: str) -> str:
        """估计查询复杂度"""
        # 基于规则的简单判断
        if len(query) < 20:
            return "simple"
        elif any(word in query for word in ["为什么", "如何", "怎样", "原理", "比较"]):
            return "complex"
        else:
            return "medium"

    def query(self, question: str, top_k: int = 3):
        """根据复杂度自适应检索"""
        complexity = self.estimate_complexity(question)

        if complexity == "simple":
            # 简单查询：使用较少的检索文档
            actual_top_k = max(1, top_k // 2)
        elif complexity == "complex":
            # 复杂查询：检索更多文档
            actual_top_k = top_k * 2
        else:
            actual_top_k = top_k

        return super().query(question, actual_top_k)

# ==================== 评估工具 ====================
class RAGEvaluator:
    """RAG系统评估器"""

    @staticmethod
    def evaluate_retrieval(
        rag_system: RAGSystem,
        test_questions: List[Dict[str, str]]
    ) -> Dict:
        """评估检索质量"""

        results = {
            'mrr': [],  # Mean Reciprocal Rank
            'precision_at_k': [],
            'recall_at_k': []
        }

        for item in test_questions:
            question = item['question']
            relevant_docs = set(item.get('relevant_docs', []))

            retrieved = rag_system.vector_store.search(question, n_results=10)

            # 计算MRR
            for i, doc in enumerate(retrieved):
                doc_id = doc['metadata'].get('source_doc_id', -1)
                if doc_id in relevant_docs:
                    results['mrr'].append(1 / (i + 1))
                    break
            else:
                results['mrr'].append(0)

            # 计算Precision@K和Recall@K
            for k in [3, 5, 10]:
                retrieved_ids = set([
                    doc['metadata'].get('source_doc_id', -1)
                    for doc in retrieved[:k]
                ])

                precision = len(retrieved_ids & relevant_docs) / k
                recall = len(retrieved_ids & relevant_docs) / len(relevant_docs) if relevant_docs else 0

                results['precision_at_k'].append({'k': k, 'score': precision})
                results['recall_at_k'].append({'k': k, 'score': recall})

        # 汇总结果
        summary = {
            'mrr': np.mean(results['mrr']),
            'precision_at_3': np.mean([r['score'] for r in results['precision_at_k'] if r['k'] == 3]),
            'precision_at_5': np.mean([r['score'] for r in results['precision_at_k'] if r['k'] == 5]),
            'recall_at_3': np.mean([r['score'] for r in results['recall_at_k'] if r['k'] == 3]),
            'recall_at_5': np.mean([r['score'] for r in results['recall_at_k'] if r['k'] == 5]),
        }

        return summary

# ==================== 主程序 ====================
def main():
    print("="*70)
    print("RAG检索增强生成系统演示")
    print("="*70)

    # 示例文档
    sample_documents = [
        """
        人工智能（AI）是计算机科学的一个分支，致力于创建能够执行通常需要人类智能的任务的系统。
        这些任务包括语言理解、学习、推理、感知和问题解决。现代AI技术主要基于机器学习和深度学习。
        """,
        """
        机器学习是AI的子领域，使计算机能够从数据中学习并改进，而无需明确编程。
        主要的机器学习类型包括监督学习、无监督学习和强化学习。
        """,
        """
        深度学习是机器学习的分支，使用多层神经网络从大量数据中学习。
        它在图像识别、自然语言处理和语音识别等领域取得了突破性成果。
        """,
        """
        自然语言处理（NLP）是AI的重要应用领域，专注于计算机与人类语言之间的交互。
        主要任务包括文本分类、情感分析、机器翻译和问答系统。
        """,
        """
        计算机视觉是使计算机能够理解和解释视觉信息的技术。
        应用包括人脸识别、物体检测、图像分割和自动驾驶中的视觉感知。
        """
    ]

    # 创建RAG系统
    print("\n初始化RAG系统...")
    embedding_model = SentenceTransformerEmbedding()
    rag_system = RAGSystem(embedding_model)

    # 摄取文档
    print("\n摄取文档到知识库...")
    rag_system.ingest_documents(sample_documents)

    # 查询示例
    questions = [
        "什么是深度学习？",
        "机器学习和人工智能有什么关系？",
        "计算机视觉有哪些应用？",
        "自然语言处理的主要任务是什么？"
    ]

    print("\n" + "="*70)
    print("RAG查询演示")
    print("="*70)

    for question in questions:
        print(f"\n问题：{question}")
        print("-"*70)

        result = rag_system.query(question, top_k=2)

        print("检索到的相关文档：")
        for i, doc in enumerate(result['retrieved_docs'], 1):
            print(f"\n[文档 {i}] (相似度: {1-doc['distance']:.3f})")
            print(doc['text'][:200] + "...")

        print(f"\n生成的增强提示：")
        print(result['prompt'][:300] + "...")

    # RAG技术对比表
    print("\n" + "="*70)
    print("RAG技术对比")
    print("="*70)

    comparison_table = """
    | RAG变体 | 特点 | 优势 | 劣势 | 适用场景 |
    |---------|------|------|------|----------|
    | Naive RAG | 一次检索直接生成 | 简单快速 | 上下文可能不足 | 简单问答 |
    | Recursive RAG | 迭代检索细化 | 提高检索质量 | 计算开销大 | 复杂查询 |
    | Hybrid RAG | 向量+关键词检索 | 互补优势 | 实现复杂 | 多样化查询 |
    | Adaptive RAG | 根据查询调整策略 | 动态优化 | 需要额外训练 | 生产环境 |
    | Modular RAG | 模块化可配置 | 灵活性高 | 集成复杂 | 企业应用 |
    """

    print(comparison_table)

    # 保存配置
    config = {
        "embedding_model": "sentence-transformers/all-MiniLM-L6-v2",
        "vector_db": "chromadb",
        "chunk_size": 1000,
        "overlap": 200,
        "top_k": 3,
        "temperature": 0.7
    }

    with open('C:/Users/PC/Desktop/MD/rag_config.json', 'w', encoding='utf-8') as f:
        json.dump(config, f, indent=2, ensure_ascii=False)

    print("\n配置已保存到 rag_config.json")

# ==================== 资源表格 ====================
resources = """
## 相关资源

| 资源类型 | 名称 | 链接 |
|---------|------|------|
| 论文 | Retrieval-Augmented Generation for Knowledge-Intensive NLP | https://arxiv.org/abs/2005.11401 |
| 框架 | LangChain | https://python.langchain.com/ |
| 框架 | LlamaIndex | https://www.llamaindex.ai/ |
| 向量数据库 | ChromaDB | https://www.trychroma.com/ |
| 向量数据库 | Pinecone | https://www.pinecone.io/ |
| 向量数据库 | Milvus | https://milvus.io/ |
| 嵌入模型 | Sentence Transformers | https://www.sbert.net/ |
| 嵌入模型 | BGE Embeddings | https://github.com/FlagOpen/FlagEmbedding |
| 教程 | RAG Tutorial | https://github.com/langchain-ai/rag |

## 向量数据库对比

| 数据库 | 开源 | 云服务 | 性能 | 特点 |
|--------|------|--------|------|------|
| ChromaDB | ✓ | - | 中 | 轻量级，易用 |
| Pinecone | - | ✓ | 高 | 托管服务，可扩展 |
| Milvus | ✓ | ✓ | 高 | 分布式，高性能 |
| Weaviate | ✓ | ✓ | 中 | 模块化架构 |
| Qdrant | ✓ | ✓ | 高 | 滤波能力强 |

## 扩展阅读

- **Advanced RAG**: 查询重写、重排序、混合检索
- **GraphRAG**: 结合知识图谱的RAG
- **Self-RAG**: 自我反思的RAG系统
- **RAGAS**: RAG系统评估框架
"""

if __name__ == "__main__":
    main()
    print(resources)

# 示例：将"如何减肥"改写为"减肥方法 饮食 运动"
def rewrite_query(query: str) -> str:
    # 实现查询扩展逻辑
    pass

# 使用交叉编码器重排序
from sentence_transformers import CrossEncoder
reranker = CrossEncoder('cross-encoder/ms-marco-MiniLM-L-6-v2')
