选项卡高度不反映自定义/用户画图TabControl上的高DPI值

Question

我已经编写了一个自定义的TabControl类，但是我无法使选项卡适应它们在高DPI屏幕上的高度。在200%缩放的屏幕上，实际选项卡页及其控件覆盖了一半，如下所示：

​

​

显然，TabControl没有调整标签高度以适应更大的字体，因此，实际页面的顶部太高，覆盖了我的选项卡。我能做些什么来加强标签来适应呢？

表单将AutoScaleMode设置为Dpi，其他一切看起来都很好，除了这个。我的目标是.NET 4.5.2，dpiAware设置在清单文件中设置为true。

以下是自定义TabControl的代码：

/// <summary>
/// A TabControl without 3D borders and other annoyances. Taken from
/// https://stackoverflow.com/questions/27469886/change-color-of-unused-space-of-tabcontrol/27472230
/// and modified.
/// </summary>
public class CleanTabControl : TabControl
{
    private class NativeMethods
    {
        [DllImport("user32.dll")] public static extern IntPtr SendMessage(IntPtr hWnd, int Msg, IntPtr wParam, IntPtr lParam);
    }
    private const int WM_SETFONT = 0x30;
    private const int WM_FONTCHANGE = 0x1d;

    private int hoverTab = -1;

    public event MouseEventHandler CloseClick;

    public CleanTabControl()
    {
        // Take over the painting completely, we want transparency and double-buffering
        SetStyle(ControlStyles.UserPaint | ControlStyles.SupportsTransparentBackColor, true);
        DoubleBuffered = ResizeRedraw = true;
    }

    protected override void OnCreateControl()
    {
        // Necessary to give tabs the correct width
        base.OnCreateControl();
        OnFontChanged(EventArgs.Empty);
    }

    protected override void OnFontChanged(EventArgs e)
    {
        // Necessary to give tabs the correct width
        base.OnFontChanged(e);
        IntPtr hFont = Font.ToHfont();
        NativeMethods.SendMessage(Handle, WM_SETFONT, hFont, (IntPtr)(-1));
        NativeMethods.SendMessage(Handle, WM_FONTCHANGE, IntPtr.Zero, IntPtr.Zero);
        UpdateStyles();
    }

    public override Color BackColor
    {
        // Override TabControl.BackColor, we need transparency
        get { return Color.Transparent; }
        set { base.BackColor = Color.Transparent; }
    }

    protected override void OnPaint(PaintEventArgs e)
    {
        // ... lot of painting code
    }

    protected override void OnMouseClick(MouseEventArgs e)
    {
        base.OnMouseClick(e);
        if (SelectedTab != null)
        {
            if (GetImageRectangle(SelectedIndex).Contains(e.Location))
                CloseClick(this, e);
        }
    }

    protected override void OnMouseMove(MouseEventArgs e)
    {
        base.OnMouseMove(e);
        hoverTab = -1;
        for (int i = 0; i < TabCount; i++)
        {
            if (GetTabRect(i).Contains(e.Location))
            {
                if (GetImageRectangle(i).Contains(e.Location))
                    TabPages[i].ImageIndex = 1;
                else
                {
                    hoverTab = i;
                    TabPages[i].ImageIndex = 0;
                }
            }
            else
                TabPages[i].ImageIndex = 0;
        }
        Invalidate();
    }

    protected override void OnMouseLeave(EventArgs e)
    {
        base.OnMouseLeave(e);
        hoverTab = -1;
        for (int i = 0; i < TabCount; i++)
        {
            TabPages[i].ImageIndex = 0;
        }
        Invalidate();
    }

    private Rectangle GetImageRectangle(int index)
    {
        Rectangle r = GetTabRect(index);
        int width = ImageList.ImageSize.Width;
        int height = ImageList.ImageSize.Height;
        int x = r.Right - width - Padding.X;
        int y = (r.Top + r.Height - height) / 2 + 1;
        if (index != SelectedIndex)
            y += 1;
        return new Rectangle(x, y, width, height);
    }
}

}

Answer 1

我找到了解决办法。在OnCreateControl()中添加：

ItemSize = new Size(ItemSize.Width, ItemSize.Height * DpiRatio);

其中，DpiRatio是标度因子(例如，200%缩放的2)。
