在选定项目更改QPen后切换QGraphicsScene

Question

如何切换所选图形视图项的QPen颜色？理想情况下，我希望在图形视图或图形场景对象中处理这种颜色变化，而不是直接在主窗口选择事件中处理它。

任何帮助都是非常感谢的。当前，当选择对象时，它将使钢笔颜色变为白色。我不知道如何回过头来避免遍历所有的对象。

我是否可以在MyGraphicsView类本身中添加一个函数来处理图形中任意和所有选定项的钢笔颜色变化？

更新:更详细的信息这里列出了我正试图解决的选择问题：

1. 当用户单击并生成选择矩形时，应取消选择所有项目，将其还原为默认的钢笔颜色。新选择的项目应该有白色钢笔的颜色。如果用户持有控制权，则应添加新选定的项。如果项目已被选中，且矩形在其上方交叉，则仍应保留所选项。
2. 如果用户单击光标下方没有项目出现的负值区域，则应清除当前选定内容。
3. 如果用户单击一个项目，它应该选择它，并使钢笔的颜色为白色。
4. 如果用户持有控制权，则应始终将其添加到选定内容中。

​

​

​

​

代码

import sys
from PySide.QtGui import *
from PySide.QtCore import *
import random


class MyGraphicsView(QGraphicsView):
    def __init__(self):
        super(MyGraphicsView, self).__init__()
        self.setDragMode(QGraphicsView.RubberBandDrag)
        self._isPanning = False
        self._mousePressed = False
        # self.setBackgroundBrush(QImage("C:/Users/jmartini/Desktop/Temp/images/flag_0140.jpg"))
        self.setCacheMode(QGraphicsView.CacheBackground)
        self.setHorizontalScrollBarPolicy( Qt.ScrollBarAlwaysOff )
        self.setVerticalScrollBarPolicy( Qt.ScrollBarAlwaysOff )


    def mousePressEvent(self,  event):
        if event.button() == Qt.LeftButton:
            self._mousePressed = True
            if self._isPanning:
                self.setCursor(Qt.ClosedHandCursor)
                self._dragPos = event.pos()
                event.accept()
            else:
                super(MyGraphicsView, self).mousePressEvent(event)
        elif event.button() == Qt.MiddleButton:
            self._mousePressed = True
            self._isPanning = True
            self.setCursor(Qt.ClosedHandCursor)
            self._dragPos = event.pos()
            event.accept()


    def mouseMoveEvent(self, event):
        if self._mousePressed and self._isPanning:
            newPos = event.pos()
            diff = newPos - self._dragPos
            self._dragPos = newPos
            self.horizontalScrollBar().setValue(self.horizontalScrollBar().value() - diff.x())
            self.verticalScrollBar().setValue(self.verticalScrollBar().value() - diff.y())
            event.accept()
        else:
            super(MyGraphicsView, self).mouseMoveEvent(event)


    def mouseReleaseEvent(self, event):
        if event.button() == Qt.LeftButton:
            if self._isPanning:
                self.setCursor(Qt.OpenHandCursor)
            else:
                self._isPanning = False
                self.setCursor(Qt.ArrowCursor)
            self._mousePressed = False
        elif event.button() == Qt.MiddleButton:
            self._isPanning = False
            self.setCursor(Qt.ArrowCursor)
            self._mousePressed = False
        super(MyGraphicsView, self).mouseReleaseEvent(event)


    def mouseDoubleClickEvent(self, event):
        self.fitInView(self.sceneRect(), Qt.KeepAspectRatio)
        pass


    def keyPressEvent(self, event):
        if event.key() == Qt.Key_Space and not self._mousePressed:
            self._isPanning = True
            self.setCursor(Qt.OpenHandCursor)
        else:
            super(MyGraphicsView, self).keyPressEvent(event)


    def keyReleaseEvent(self, event):
        if event.key() == Qt.Key_Space:
            if not self._mousePressed:
                self._isPanning = False
                self.setCursor(Qt.ArrowCursor)
        else:
            super(MyGraphicsView, self).keyPressEvent(event)


    def wheelEvent(self,  event):
        # zoom factor
        factor = 1.25

        # Set Anchors
        self.setTransformationAnchor(QGraphicsView.NoAnchor)
        self.setResizeAnchor(QGraphicsView.NoAnchor)

        # Save the scene pos
        oldPos = self.mapToScene(event.pos())

        # Zoom
        if event.delta() < 0:
            factor = 1.0 / factor
        self.scale(factor, factor)

        # Get the new position
        newPos = self.mapToScene(event.pos())

        # Move scene to old position
        delta = newPos - oldPos
        self.translate(delta.x(), delta.y())


class MyGraphicsScene(QGraphicsScene):
    def __init__(self,  parent):
        super(MyGraphicsScene,  self).__init__()
        self.setBackgroundBrush(QBrush(QColor(50,50,50)))
        # self.setSceneRect(50,50,0,0)


class MyMainWindow(QMainWindow):
    def __init__(self):
        super(MyMainWindow, self).__init__()
        self.setWindowTitle("Test")
        self.resize(800,600)

        self.gv = MyGraphicsView()
        self.gv.setScene(MyGraphicsScene(self))
        self.setCentralWidget(self.gv)

        self.gv.scene().selectionChanged.connect(self.selection_changed)
        self.populate()


    def populate(self):
        scene = self.gv.scene()

        for i in range(500):
            x = random.randint(0, 1000)
            y = random.randint(0, 1000)
            r = random.randint(2, 8)
            rect = scene.addEllipse(x, y, r, r, QPen(QColor(255,128,0), 0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin), QBrush(QColor(255,128,20,128)))
            rect.setFlag( QGraphicsItem.ItemIsSelectable )
            rect.setFlag( QGraphicsItem.ItemIsMovable )

        rect = scene.addEllipse(300, 500, 20, 20, QPen(QColor(255,128,0), 0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin), QBrush(QColor(255,0,0,128)))
        rect.setFlag( QGraphicsItem.ItemIsSelectable )
        rect.setFlag( QGraphicsItem.ItemIsMovable )


    def selection_changed(self):
        selection = self.gv.scene().selectedItems()
        print 'Selected:', len(selection)
        for i in selection:
            i.setPen(QPen(QColor(255,255,255), 0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin))


def main():
    app = QApplication(sys.argv)
    ex = MyMainWindow()
    ex.show()
    sys.exit(app.exec_())


if __name__ == '__main__':
    main()

Answer 1

应该可以通过缓存最后一个选择，然后在进行新的选择之前清除它，从而获得所需的行为：

class MyGraphicsView(QGraphicsView):
    def __init__(self):
        ...
        self.setScene(MyGraphicsScene(self))
        self.scene().selectionChanged.connect(self.selection_changed)
        self._current_selection = []

    def select_items(self, items, on):
        pen = QPen(QColor(255, 255, 255) if on else QColor(255, 128, 0),
                   0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin)
        for item in items:
            item.setPen(pen)

    def selection_changed(self):
        try:
            self.select_items(self._current_selection, False)
            self._current_selection = self.scene().selectedItems()
            self.select_items(self._current_selection, True)
        except RuntimeError:
            pass

以下是完整的脚本：

import sys
from PySide.QtGui import *
from PySide.QtCore import *
import random


class MyGraphicsView(QGraphicsView):
    def __init__(self):
        super(MyGraphicsView, self).__init__()
        self.setDragMode(QGraphicsView.RubberBandDrag)
        self._isPanning = False
        self._mousePressed = False
        self.setCacheMode(QGraphicsView.CacheBackground)
        self.setHorizontalScrollBarPolicy( Qt.ScrollBarAlwaysOff )
        self.setVerticalScrollBarPolicy( Qt.ScrollBarAlwaysOff )
        self.setScene(MyGraphicsScene(self))
        self.scene().selectionChanged.connect(self.selection_changed)
        self._current_selection = []

    def select_items(self, items, on):
        pen = QPen(QColor(255, 255, 255) if on else QColor(255, 128, 0),
                   0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin)
        for item in items:
            item.setPen(pen)

    def selection_changed(self):
        try:
            self.select_items(self._current_selection, False)
            self._current_selection = self.scene().selectedItems()
            self.select_items(self._current_selection, True)
        except RuntimeError:
            pass

    def mousePressEvent(self,  event):
        if event.button() == Qt.LeftButton:
            self._mousePressed = True
            if self._isPanning:
                self.setCursor(Qt.ClosedHandCursor)
                self._dragPos = event.pos()
                event.accept()
            else:
                super(MyGraphicsView, self).mousePressEvent(event)
        elif event.button() == Qt.MiddleButton:
            self._mousePressed = True
            self._isPanning = True
            self.setCursor(Qt.ClosedHandCursor)
            self._dragPos = event.pos()
            event.accept()


    def mouseMoveEvent(self, event):
        if self._mousePressed and self._isPanning:
            newPos = event.pos()
            diff = newPos - self._dragPos
            self._dragPos = newPos
            self.horizontalScrollBar().setValue(self.horizontalScrollBar().value() - diff.x())
            self.verticalScrollBar().setValue(self.verticalScrollBar().value() - diff.y())
            event.accept()
        else:
            super(MyGraphicsView, self).mouseMoveEvent(event)


    def mouseReleaseEvent(self, event):
        if event.button() == Qt.LeftButton:
            if self._isPanning:
                self.setCursor(Qt.OpenHandCursor)
            else:
                self._isPanning = False
                self.setCursor(Qt.ArrowCursor)
            self._mousePressed = False
        elif event.button() == Qt.MiddleButton:
            self._isPanning = False
            self.setCursor(Qt.ArrowCursor)
            self._mousePressed = False
        super(MyGraphicsView, self).mouseReleaseEvent(event)


    def mouseDoubleClickEvent(self, event):
        self.fitInView(self.sceneRect(), Qt.KeepAspectRatio)
        pass


    def keyPressEvent(self, event):
        if event.key() == Qt.Key_Space and not self._mousePressed:
            self._isPanning = True
            self.setCursor(Qt.OpenHandCursor)
        else:
            super(MyGraphicsView, self).keyPressEvent(event)


    def keyReleaseEvent(self, event):
        if event.key() == Qt.Key_Space:
            if not self._mousePressed:
                self._isPanning = False
                self.setCursor(Qt.ArrowCursor)
        else:
            super(MyGraphicsView, self).keyPressEvent(event)


    def wheelEvent(self,  event):
        # zoom factor
        factor = 1.25

        # Set Anchors
        self.setTransformationAnchor(QGraphicsView.NoAnchor)
        self.setResizeAnchor(QGraphicsView.NoAnchor)

        # Save the scene pos
        oldPos = self.mapToScene(event.pos())

        # Zoom
        if event.delta() < 0:
            factor = 1.0 / factor
        self.scale(factor, factor)

        # Get the new position
        newPos = self.mapToScene(event.pos())

        # Move scene to old position
        delta = newPos - oldPos
        self.translate(delta.x(), delta.y())


class MyGraphicsScene(QGraphicsScene):
    def __init__(self,  parent):
        super(MyGraphicsScene,  self).__init__()
        self.setBackgroundBrush(QBrush(QColor(50,50,50)))
        # self.setSceneRect(50,50,0,0)


class MyMainWindow(QMainWindow):
    def __init__(self):
        super(MyMainWindow, self).__init__()
        self.setWindowTitle("Test")
        self.resize(800,600)
        self.gv = MyGraphicsView()
        self.setCentralWidget(self.gv)
        self.populate()

    def populate(self):
        scene = self.gv.scene()
        for i in range(500):
            x = random.randint(0, 1000)
            y = random.randint(0, 1000)
            r = random.randint(2, 8)
            rect = scene.addEllipse(x, y, r, r, QPen(QColor(255,128,0), 0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin), QBrush(QColor(255,128,20,128)))
            rect.setFlag( QGraphicsItem.ItemIsSelectable )
            rect.setFlag( QGraphicsItem.ItemIsMovable )

        rect = scene.addEllipse(300, 500, 20, 20, QPen(QColor(255,128,0), 0.5, Qt.SolidLine, Qt.RoundCap, Qt.RoundJoin), QBrush(QColor(255,0,0,128)))
        rect.setFlag( QGraphicsItem.ItemIsSelectable )
        rect.setFlag( QGraphicsItem.ItemIsMovable )


def main():
    app = QApplication(sys.argv)
    ex = MyMainWindow()
    ex.show()
    sys.exit(app.exec_())


if __name__ == '__main__':
    main()
