wordcloud2闪亮的输出创建额外的小部件

Question

使用wordcloud2 cran页面(https://cran.r-project.org/web/packages/wordcloud2/vignettes/wordcloud.html)上的示例，我在wordcloud下面得到了一个小的额外框。每当我使用wordcloud2包的r闪亮功能时，就会发生这种情况：

​

​

生成此代码的代码只是：

library(wordcloud2)
# Global variables can go here
n <- 1

# Define the UI
ui <- bootstrapPage(
  numericInput('size', 'Size of wordcloud', n),
  wordcloud2Output('wordcloud2')
)


# Define the server code
server <- function(input, output) {
  output$wordcloud2 <- renderWordcloud2({
    # wordcloud2(demoFreqC, size=input$size)
    wordcloud2(demoFreq, size=input$size)
  })
}
shinyApp(ui = ui, server = server)

Answer 1

删除该框的一种方法是使用CSS样式将元素设置为“不显示”。只需将此代码添加到UI的主体中，就可以做到这一点：

tags$head(
      tags$style(HTML('div#wcLabel {display: none;}'))
    )

请注意，这也扼杀了滚动功能，该功能显示当您悬停在一个单词上时术语的频率。就我而言，这是可取的。

Answer 2

我通过使用这个wordcloud2a()函数而不是普通的wordcloud2()来解决问题。

wordcloud2a <- function (data, size = 1, minSize = 0, gridSize = 0, fontFamily = "Segoe UI",
          fontWeight = "bold", color = "random-dark", backgroundColor = "white",
          minRotation = -pi/4, maxRotation = pi/4, shuffle = TRUE,
          rotateRatio = 0.4, shape = "circle", ellipticity = 0.65,
          widgetsize = NULL, figPath = NULL, hoverFunction = NULL)
{
  if ("table" %in% class(data)) {
    dataOut = data.frame(name = names(data), freq = as.vector(data))
  }
  else {
    data = as.data.frame(data)
    dataOut = data[, 1:2]
    names(dataOut) = c("name", "freq")
  }
  if (!is.null(figPath)) {
    if (!file.exists(figPath)) {
      stop("cannot find fig in the figPath")
    }
    spPath = strsplit(figPath, "\\.")[[1]]
    len = length(spPath)
    figClass = spPath[len]
    if (!figClass %in% c("jpeg", "jpg", "png", "bmp", "gif")) {
      stop("file should be a jpeg, jpg, png, bmp or gif file!")
    }
    base64 = base64enc::base64encode(figPath)
                    base64)
  }
  else {
    base64 = NULL
  }
  weightFactor = size * 180/max(dataOut$freq)
  settings <- list(word = dataOut$name, freq = dataOut$freq,
                   fontFamily = fontFamily, fontWeight = fontWeight, color = color,
                   minSize = minSize, weightFactor = weightFactor, backgroundColor = backgroundColor,
                   gridSize = gridSize, minRotation = minRotation, maxRotation = maxRotation,
                   shuffle = shuffle, rotateRatio = rotateRatio, shape = shape,
                   ellipticity = ellipticity, figBase64 = base64, hover = htmlwidgets::JS(hoverFunction))
  chart = htmlwidgets::createWidget("wordcloud2", settings,
                                    width = widgetsize[1], height = widgetsize[2], sizingPolicy = htmlwidgets::sizingPolicy(viewer.padding = 0,
                                                                                                                            browser.padding = 0, browser.fill = TRUE))
  chart
}

有关进一步解释/讨论，请参见这里
