如何在UIImage中屏蔽UIView视图？

Question

我试图将子视图伪装成超级视图，但是图像视图并不被屏蔽为超级视图。

如何显示

​

它怎么会是

​

​

码

class TicketView: UIView {

    var img = UIImage(named: "social-event.jpg")
    var imageView = UIImageView()

    override func draw(_ rect: CGRect) {
        let path = UIBezierPath(rect: rect)
        let width:CGFloat = 11
        let height:CGFloat = 11
        let roundLeft = UIBezierPath(roundedRect: CGRect(x: -(width/2), y: -(height/2), width: width, height: height), cornerRadius: (height/2))
        let roundLeftBotton = UIBezierPath(roundedRect: CGRect(x: -(width/2), y: (rect.height)-(height/2), width: width, height: height), cornerRadius: (height/2))
        let roundRight = UIBezierPath(roundedRect: CGRect(x: (rect.width)-(width/2), y: -(height/2), width: width, height: height), cornerRadius: (height/2))
        let roundRightBottom = UIBezierPath(roundedRect: CGRect(x: (rect.width)-(width/2), y: (rect.height)-(height/2), width: width, height: height), cornerRadius: (height/2))

        let roundRightMiddle = UIBezierPath(roundedRect: CGRect(x: (rect.width*0.7)-(width/2), y: -(height/2), width: width, height: height), cornerRadius: (height/2))
        let roundRightMiddleBottom = UIBezierPath(roundedRect: CGRect(x: (rect.width*0.7)-(width/2), y:
            (rect.height)-(height/2), width: width, height: height), cornerRadius: (height/2))
        path.append(roundLeft.reversing())
        path.append(roundLeftBotton.reversing())
        path.append(roundRight.reversing())
        path.append(roundRightBottom.reversing())
        path.append(roundRightMiddle.reversing())
        path.append(roundRightMiddleBottom.reversing())

        UIColor.green.setFill()
        path.fill()

        imageView.frame = CGRect(x: 0, y: 0, width: (rect.width * 0.7),  height: rect.height)
        imageView.backgroundColor = UIColor.black
        self.addSubview(imageView)


    }

}

我到现在为止尝试过的

1)掩模层

2)切割图像

Answer 1

制作新的图像，有图层，就像你的角落，并把你的观点作为一个面具。
