UWP: Grid.IsSharedSizeScope和SharedSizeGroup的替代方案

Question

我在下面的论坛上看到了同样的问题：MSDN问题

然而，出于某种原因，微软决定删除这里描述的答案中的功能。

我要寻找的是一个带有ListView列的2+列，其中第一列包含随机数据(因此是随机宽度元素)，使得第一列的宽度与最宽的元素相同。

Answer 1

SharedSizeGroup是WPF的独占，在UWP中不存在。

目标:创建SharedSizeGroup的替代方案

为了知道度量，我们需要查看所有的控件并找到最大值。

我们要做的是

我们使用福迪和PropertyChanged.Fody nuget软件包。虽然它们不是只读示例所必需的，但是如果您开始修改数据，它们是有用的。我添加SizeChanged事件处理程序并直接修改宽度。您可以设置属性并将其绑定到属性或创建行为，但这就是它的实现方式。

​

​

视图

<Page
    x:Class="TestUwp.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:local="using:TestUwp"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    d:DataContext="{d:DesignInstance Type=local:DataItem}"
    Background="{ThemeResource ApplicationPageBackgroundThemeBrush}"
    mc:Ignorable="d">

    <ListView ItemsSource="{Binding TestData}">
        <ListView.ItemTemplate>
            <DataTemplate>
                <StackPanel>
                    <Grid ColumnSpacing="6" RowSpacing="6">
                        <Grid.ColumnDefinitions>
                            <ColumnDefinition Width="Auto" />
                            <ColumnDefinition Width="*" />
                        </Grid.ColumnDefinitions>
                        <TextBlock
                            Grid.Column="0"
                            SizeChanged="LabelSizeChanged"
                            Text="{Binding FirstName}" />
                        <TextBlock Grid.Column="1" Text="{Binding LastName}" />
                    </Grid>
                </StackPanel>
            </DataTemplate>
        </ListView.ItemTemplate>
    </ListView>
</Page>

模型与ViewModel

using System.Collections.Generic;
using System.Collections.ObjectModel;
using System.ComponentModel;
using Windows.UI.Xaml;
using Windows.UI.Xaml.Controls;

namespace TestUwp
{
    public class DataItem : INotifyPropertyChanged
    {
        public DataItem(int id, string firstName, string lastName)
        {
            Id = id;
            FirstName = firstName;
            LastName = lastName;
        }

        public int Id { get; set; }
        public string FirstName { get; set; }
        public string LastName { get; set; }

        public event PropertyChangedEventHandler PropertyChanged;
    }

    public sealed partial class MainPage : Page
    {
        public MainPage()
        {
            this.InitializeComponent();
            TestData = new ObservableCollection<DataItem> {
                new DataItem(1, "Pauly", "Thurlborn"),
                new DataItem(2, "Orbadiah", "Ewen"),
                new DataItem(3, "Britni"  ,"Smead"),
                new DataItem(4, "Fionna"  ,"Jennemann"),
                new DataItem(5, "Ashley" ,"Stoddart"),
                new DataItem(6, "Bradford", "Kaesmakers"),
                new DataItem(7, "Maxy" ,"Lemon"),
                new DataItem(8, "Rasia" ,"Comber"),
                new DataItem(9, "Colas" ,"Shepton"),
                new DataItem(10, "Cacilie" ,"Tummons"),
            };
            DataContext = this;
        }
        public ObservableCollection<DataItem> TestData { get; set; }
        private List<ColumnDefinition> _columns = new List<ColumnDefinition>();
        private double _colSize = 0.0;
        private void LabelSizeChanged(object sender, SizeChangedEventArgs e)
        {
            var item = (dynamic)sender;
            var grid = (Grid)item.Parent;
            var column = grid.ColumnDefinitions[0];
            if (!_columns.Contains(column))
            {
                _columns.Add(column);
            }
            var adjustments = new List<ColumnDefinition>();
            if (item.ActualWidth > _colSize)
            {
                _colSize = item.ActualWidth;
                adjustments.AddRange(_columns);
            }
            else
            {
                adjustments.Add(column);
            }
            foreach (var col in adjustments)
            {
                col.Width = new GridLength(_colSize);
            }
        }
    }
}

这种想法的来源来源于扎马林。

Answer 2

我认为这个堆叠溢出问题中给出的解决方案应该做您想做的事情，您只需将第一列改为Auto而不是*

从岗位：

<Page.Resources>

    <DataTemplate x:Key="DataTemplate1"  >
        <Grid HorizontalAlignment="Stretch" VerticalAlignment="Stretch" Background="Gray">
            <Grid.ColumnDefinitions>
                <ColumnDefinition Width="*" />
                <ColumnDefinition Width="*"/>
                <ColumnDefinition Width="*"/>
            </Grid.ColumnDefinitions>
            <StackPanel Grid.Column="0" HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
                <TextBlock Text="{Binding Name1}"/>
            </StackPanel>
            <StackPanel Grid.Column="1" HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
                <TextBlock Text="{Binding Name2}"/>

            </StackPanel>
            <StackPanel Grid.Column="2" HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
                <TextBlock Text="{Binding Name3}"/>

            </StackPanel>
        </Grid>
    </DataTemplate>
</Page.Resources>

<Grid Background="{StaticResource ApplicationPageBackgroundThemeBrush}" HorizontalAlignment="Stretch" VerticalAlignment="Stretch">

    <ListView Name="MyList" HorizontalAlignment="Stretch" HorizontalContentAlignment="Stretch"  VerticalContentAlignment="Stretch" VerticalAlignment="Stretch" Background="Yellow" ItemTemplate="{StaticResource DataTemplate1}">

        <ListView.ItemContainerStyle>
            <Style TargetType="ListViewItem">
                <Setter Property="HorizontalContentAlignment" Value="Stretch"></Setter>
            </Style>
        </ListView.ItemContainerStyle>
        <ListView.ItemsPanel>

            <ItemsPanelTemplate
                <!-- Here is the panel that will contain the items -->
                <StackPanel Orientation="Vertical" HorizontalAlignment="Stretch" Background="Pink" VerticalAlignment="Stretch"/>
            </ItemsPanelTemplate>
        </ListView.ItemsPanel>
    </ListView>
</Grid>

还有后面的密码。只是为了尝试一下，没有使用MVVM。

这是cs

        List<test> li = new List<test>();
    /// <summary>
    /// Invoked when this page is about to be displayed in a Frame.
    /// </summary>
    /// <param name="e">Event data that describes how this page was reached.  The Parameter
    /// property is typically used to configure the page.</param>
    protected async override void OnNavigatedTo(NavigationEventArgs e)
    {
        for (int i = 0; i < 10; i++)
        {
            li.Add(new test()
            {
                Name1 = "Anobik1" + i.ToString(),
                Name2 = "Anobik1"                    +i.ToString(),
                Name3 = "Anobik1"                    +i.ToString()
            });
        }
        MyList.ItemsSource = li;

    }

我绑定的类如下所示

 class test
{
    public string Name1 { get; set; }
    public string Name2 { get; set; }
    public string Name3 { get; set; }
}
