让LaTeX中的代码看起来*很好*
EN

Stack Overflow用户
提问于 2009-02-25 15:49:17
回答 3查看 123.7K关注 0票数 137

我目前正在编写一份项目报告,为了解释我所使用的有点疯狂的不直观的代码,我需要将大量大量的示例代码摘录到其中。

如何将代码输入到LaTeX中:

  • 看上去不错
  • 如果行太长(列出列表或逐字),则不会离开页面的一侧。
  • 最好与文本的其余部分保持一致。

编辑(我想我会添加设置,这样人们就不用自己想办法弄清楚了)(摘自wikibook(链接更低),编辑得更好)。

不错的设置:

代码语言:javascript
复制
\usepackage{color}
\usepackage{listings}
\lstset{ %
language=C++,                % choose the language of the code
basicstyle=\footnotesize,       % the size of the fonts that are used for the code
numbers=left,                   % where to put the line-numbers
numberstyle=\footnotesize,      % the size of the fonts that are used for the line-numbers
stepnumber=1,                   % the step between two line-numbers. If it is 1 each line will be numbered
numbersep=5pt,                  % how far the line-numbers are from the code
backgroundcolor=\color{white},  % choose the background color. You must add \usepackage{color}
showspaces=false,               % show spaces adding particular underscores
showstringspaces=false,         % underline spaces within strings
showtabs=false,                 % show tabs within strings adding particular underscores
frame=single,           % adds a frame around the code
tabsize=2,          % sets default tabsize to 2 spaces
captionpos=b,           % sets the caption-position to bottom
breaklines=true,        % sets automatic line breaking
breakatwhitespace=false,    % sets if automatic breaks should only happen at whitespace
escapeinside={\%*}{*)}          % if you want to add a comment within your code
}

\begin{lstlisting}
!!code!!
\end{lstlisting}

这些设置的一个示例:

EN

回答 3

Stack Overflow用户

回答已采纳

发布于 2009-02-25 15:51:45

列单包非常漂亮,非常灵活(例如,用于注释和代码的不同大小)。

票数 42
EN

Stack Overflow用户

发布于 2009-02-25 17:25:34

事实证明,lstlisting能够很好地格式化代码,但需要进行大量的调整。

对于可以调整的参数,维基百科有一个很好的示例。

票数 18
EN

Stack Overflow用户

发布于 2009-02-25 15:54:07

对于简单的文档,我有时会逐字使用,但是对于大量代码块来说,清单是很好的。

票数 2
