如何实现“Autodesk.AEC.LevelsExtension”和“Autodesk.AEC.Minimap3DExtension”

Question

我试图实现‘implement .AEC.LevelsExtenation’。还有“Autodesk.AEC.Minimap3DExtension”，但对我来说不管用。我已经实现了您在post https://forge.autodesk.com/blog/new-rvt-svf-model-derivative-parameter-generates-additional-content-including-rooms-and-spaces中推荐的内容

我使用下面的方法来转换模型，但是我仍然没有关于级别的信息。

  var format_type = "svf";
  var format_views = ["2d", "3d"];
  Axios({
    method: "POST",
    url: "https://developer.api.autodesk.com/modelderivative/v2/designdata/job",
    headers: {
      "content-type": "application/json",
      Authorization: "Bearer " + access_token,
      'x-ads-force': true
   },
   data: JSON.stringify({
   input: {
    urn: urn
   },
   output: {
    formats: [
      {
        type: format_type,
        views: format_views,
        "advanced": {
          "generateMasterViews": true
          }
        }
      ]
    }
  })
})

注意:我使用Autodesk rac_basic_sample_project.rvt和rac_advanced_sample_project.rvt模型

​

​

Answer 1

我们能够通过使用downloadAecModelData ()方法找到解决方案

function onDocumentLoadSuccess(viewerDocument) {
  var defaultModel = viewerDocument.getRoot().getDefaultGeometry();
  viewer.loadDocumentNode(viewerDocument, defaultModel);
  viewerDocument.downloadAecModelData()
}
