用Vegalite绘制多直方图图

Question

我想创造一个单一的视觉显示多个直方图在它上。我有一些简单的值数组，如下所示：

"data": {"values": {"foo": [0,0,0,1,1,1,2,2,2], "baz": [2,2,2,3,3,3,4,4,4]}}

我想使用不同的颜色条来显示"foo“和"baz”的值的扩展。我可以为"foo“做一个直方图，如下所示：

{
  "data": {"values": {"foo": [0,0,0,1,1,1,2,2,2]}},
  "mark": "bar",
  "transform": [{"flatten": ["foo"]}],
  "encoding": {
    "x": {"field": "foo", "type": "quantitative"},
    "y": {"field": "foo", "type": "quantitative", "aggregate": "count"}
  }
}

但是，我无法找到正确的方法来平平数组。这不管用：

{
  "data": {"values": {"foo": [0,0,0,1,1,1,2,2,2], "bar": [0,0,0,1,1,1,2,2,2]}},
  "mark": "bar",
  "transform": [{"flatten": ["foo", "baz"]}],
  "encoding": {
    "x": {"field": "foo", "type": "quantitative"},
    "y": {"field": "foo", "type": "quantitative", "aggregate": "count"}
  },
  "layer": [{
    "mark": "bar",
    "encoding": {
      "y": {"field": "baz", "type": "quantitative", "aggregate": "count"}
    }
  }]
}

https://vega.github.io/editor/#/url/vega-lite/N4IgJghgLhIFygG4QDYFcCmBneoBmA9gfANoAMANJZQIwV10BMFzjAuhSAEYQBep1KvWFMWLNgF8JnALYQATgGt43BSE5R5EAHZZC8maXwpoUDNtIhCxTj36SOIcwGMCYAJbaA5rhAAPXzx3DBQwFWt1ECgATwAHDBUARzQdKHcYNMQE6RBowODQ8KJImPiklO00jPcsyIgvL3kML2gEuBBXNEqQKU4TaIx5IxA5JRUeIc4XN08fBFz8kLD2uxK4tpBk1PToGoTOesbm1pVO7qkJSSA

检查data_0时，foo和它的计数都有列，而baz则没有。

这也不起作用：

{
  "data": {
    "values": {
      "foo": [0, 0, 0, 1, 1, 1, 2, 2, 2],
      "baz": [0, 0, 0, 1, 1, 1, 2, 2, 2]
    }
  },
  "mark": "bar",
  "transform": [{"flatten": ["foo"]},{"flatten": ["baz"]}],
  "encoding": {
    "x": {"field": "foo", "type": "quantitative"},
    "y": {"field": "foo", "type": "quantitative", "aggregate": "count"}
  },
  "layer": [
    {
      "mark": "bar",
      "encoding": {
        "y": {"field": "baz", "type": "quantitative", "aggregate": "count"}
      }
    }
  ]
}

https://vega.github.io/editor/#/url/vega-lite/N4IgJghgLhIFygG4QDYFcCmBneoBmA9gfANoAMANJZQIwV10BMFzjAuhSAEYQBep1KvWFMWLNgF8JnALYQATgGt43BSE5R5EAHZZC8maXwpoUDNtIhCxSRWOnzlnv0kcQ5gMYEwAS20BzXBAADyC8HwwUMBVrdRAoAE8ABwwVAEc0HSgfGGzEVOkQBLCIqJiiOMSU9MztbNyffLiIf395DH9oVLgQLzQ6kClOEwSMeSMQOSUVHnHOT28-QIQiksjonudK5O6QDKyc6EbUzha2jq6VPoGpCUkgA

这仍然只给出了foo及其计数的列，但是现在每个桶的计数是27！

如何实现从数组数据开始的多直方图图形？

Answer 1

您可以使用一个平坦变换和一个褶皱变换来完成这个任务，然后使用颜色编码来分离这两个数据集。例如(开放编辑器)：

{
  "data": {
    "values": {
      "foo": [0, 0, 1, 1, 1, 1, 2, 2, 2],
      "baz": [4, 4, 5, 5, 6, 6, 6, 6, 7]
    }
  },
  "transform": [{"flatten": ["foo", "baz"]}, {"fold": ["foo", "baz"]}],
  "mark": "bar",
  "encoding": {
    "x": {"field": "value", "type": "quantitative"},
    "y": {
      "field": "value",
      "type": "quantitative",
      "aggregate": "count",
      "stack": null
    },
    "color": {"field": "key", "type": "nominal"}
  }
}

​

​

另外，如果将编码放在单独的层中，则层方法也可以工作，这样外部foo聚合不会破坏baz数据，但它比基于折叠的方法要详细一些

{
  "data": {
    "values": {
      "foo": [0, 0, 1, 1, 1, 1, 2, 2, 2],
      "baz": [4, 4, 5, 5, 6, 6, 6, 6, 7]
    }
  },
  "transform": [{"flatten": ["foo", "baz"]}],
  "layer": [
    {
      "mark": {"type": "bar", "color": "orange"},
      "encoding": {
        "x": {"field": "foo", "type": "quantitative"},
        "y": {"field": "foo", "type": "quantitative", "aggregate": "count"}
      }
    },
    {
      "mark": "bar",
      "encoding": {
        "x": {"field": "baz", "type": "quantitative"},
        "y": {"field": "baz", "type": "quantitative", "aggregate": "count"}
      }
    }
  ]
}
