Question

我目前正在设置sentry.io，但在openshift 3.11中设置它时遇到了问题

我为sentry本身、postgresql、redis和memcache运行了pods，但是根据日志消息，它们无法在一起进行通信。

sentry.exceptions.InvalidConfiguration: Error 111 connecting to 127.0.0.1:6379. Connection refused.

我是否需要创建一个类似于docker的网络，或者在默认情况下，豆荚(都在同一个名称空间中)应该能够相互通信？我获得了整个项目的管理权限，所以我也可以使用控制台，而不仅仅是网络界面。

谨致问候

编辑：为sentry及其服务添加部署配置，并为简单起见添加postgres配置和服务。我还删除了一些不必要的信息与关键字BLANK，如果我走了，请让我知道，我来查。

sentry的部署配置

apiVersion: apps.openshift.io/v1
kind: DeploymentConfig
metadata:
  annotations:
    openshift.io/generated-by: OpenShiftWebConsole
  creationTimestamp: BLANK
  generation: 20
  labels:
    app: sentry
  name: sentry
  namespace: test
  resourceVersion: '506667843'
  selfLink: BLANK
  uid: BLANK
spec:
  replicas: 1
  selector:
    app: sentry
    deploymentconfig: sentry
  strategy:
    activeDeadlineSeconds: 21600
    resources: {}
    rollingParams:
      intervalSeconds: 1
      maxSurge: 25%
      maxUnavailable: 25%
      timeoutSeconds: 600
      updatePeriodSeconds: 1
    type: Rolling
  template:
    metadata:
      annotations:
        openshift.io/generated-by: OpenShiftWebConsole
      creationTimestamp: null
      labels:
        app: sentry
        deploymentconfig: sentry
    spec:
      containers:
        - env:
            - name: SENTRY_SECRET_KEY
              value: Iamsosecret
            - name: C_FORCE_ROOT
              value: '1'
            - name: SENTRY_FILESTORE_DIR
              value: /var/lib/sentry/files/data
          image: BLANK
          imagePullPolicy: Always
          name: sentry
          ports:
            - containerPort: 9000
              protocol: TCP
          resources: {}
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          volumeMounts:
            - mountPath: /var/lib/sentry/files
              name: sentry-1
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      terminationGracePeriodSeconds: 30
      volumes:
        - emptyDir: {}
          name: sentry-1
  test: false
  triggers:
    - type: ConfigChange
    - imageChangeParams:
        automatic: true
        containerNames:
          - sentry
        from:
          kind: ImageStreamTag
          name: 'sentry:latest'
          namespace: catcloud
        lastTriggeredImage: BLANK
      type: ImageChange
status:
  availableReplicas: 1
  conditions:
    - lastTransitionTime: BLANK
      lastUpdateTime: BLANK
      message: Deployment config has minimum availability.
      status: 'True'
      type: Available
    - lastTransitionTime: BLANK
      lastUpdateTime: BLANK
      message: replication controller "sentry-19" successfully rolled out
      reason: NewReplicationControllerAvailable
      status: 'True'
      type: Progressing
  details:
    causes:
      - type: ConfigChange
    message: config change
  latestVersion: 19
  observedGeneration: 20
  readyReplicas: 1
  replicas: 1
  unavailableReplicas: 0
  updatedReplicas: 1

sentry服务

apiVersion: v1
kind: Service
metadata:
  annotations:
    openshift.io/generated-by: OpenShiftWebConsole
  creationTimestamp: BLANK
  labels:
    app: sentry
  name: sentry
  namespace: test
  resourceVersion: '505555608'
  selfLink: BLANK
  uid: BLANK
spec:
  clusterIP: BLANK
  ports:
    - name: 9000-tcp
      port: 9000
      protocol: TCP
      targetPort: 9000
  selector:
    deploymentconfig: sentry
  sessionAffinity: None
  type: ClusterIP
status:
  loadBalancer: {}

postgresql的部署配置

apiVersion: apps.openshift.io/v1
kind: DeploymentConfig
metadata:
  annotations:
    openshift.io/generated-by: OpenShiftWebConsole
  creationTimestamp: BLANK
  generation: 10
  labels:
    app: postgres
    type: backend
  name: postgres
  namespace: test
  resourceVersion: '506664185'
  selfLink: BLANK
  uid: BLANK
spec:
  replicas: 1
  selector:
    app: postgres
    deploymentconfig: postgres
    type: backend
  strategy:
    activeDeadlineSeconds: 21600
    resources: {}
    rollingParams:
      intervalSeconds: 1
      maxSurge: 25%
      maxUnavailable: 25%
      timeoutSeconds: 600
      updatePeriodSeconds: 1
    type: Rolling
  template:
    metadata:
      annotations:
        openshift.io/generated-by: OpenShiftWebConsole
      creationTimestamp: null
      labels:
        app: postgres
        deploymentconfig: postgres
        type: backend
    spec:
      containers:
        - env:
            - name: PGDATA
              value: /var/lib/postgresql/data/sql
            - name: POSTGRES_HOST_AUTH_METHOD
              value: trust
            - name: POSTGRESQL_USER
              value: sentry
            - name: POSTGRESQL_PASSWORD
              value: sentry
            - name: POSTGRESQL_DATABASE
              value: sentry
          image: BLANK
          imagePullPolicy: Always
          name: postgres
          ports:
            - containerPort: 5432
              protocol: TCP
          resources: {}
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          volumeMounts:
            - mountPath: /var/lib/postgresql/data
              name: volume-uirge
              subPath: sql
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext:
        runAsUser: 2000020900
      terminationGracePeriodSeconds: 30
      volumes:
        - name: volume-uirge
          persistentVolumeClaim:
            claimName: postgressql
  test: false
  triggers:
    - type: ConfigChange
    - imageChangeParams:
        automatic: true
        containerNames:
          - postgres
        from:
          kind: ImageStreamTag
          name: 'postgres:latest'
          namespace: catcloud
        lastTriggeredImage: BLANK
      type: ImageChange
status:
  availableReplicas: 1
  conditions:
    - lastTransitionTime: BLANK
      lastUpdateTime: BLANK
      message: Deployment config has minimum availability.
      status: 'True'
      type: Available
    - lastTransitionTime: BLANK
      lastUpdateTime: BLANK
      message: replication controller "postgres-9" successfully rolled out
      reason: NewReplicationControllerAvailable
      status: 'True'
      type: Progressing
  details:
    causes:
      - type: ConfigChange
    message: config change
  latestVersion: 9
  observedGeneration: 10
  readyReplicas: 1
  replicas: 1
  unavailableReplicas: 0
  updatedReplicas: 1

服务配置postgresql

apiVersion: v1
kind: Service
metadata:
  annotations:
    openshift.io/generated-by: OpenShiftWebConsole
  creationTimestamp: BLANK
  labels:
    app: postgres
    type: backend
  name: postgres
  namespace: catcloud
  resourceVersion: '506548841'
  selfLink: /api/v1/namespaces/catcloud/services/postgres
  uid: BLANK
spec:
  clusterIP: BLANK
  ports:
    - name: 5432-tcp
      port: 5432
      protocol: TCP
      targetPort: 5432
  selector:
    deploymentconfig: postgres
  sessionAffinity: None
  type: ClusterIP
status:
  loadBalancer: {}

Answer 1

在默认情况下，豆荚(即使在同一个名称空间中)也不能直接与对话。您需要创建一个Service，以便允许一个吊舱接收来自另一个吊舱的连接。一般来说，一个吊舱通过后者的服务连接到另一个吊舱，如下所示：

​

​

连接信息看起来类似于<servicename>:<serviceport> (例如，elasticsearch-master:9200)，而不是localhost:port。

有关服务的更多信息，您可以阅读https://kubernetes.io/docs/concepts/services-networking/service/。

注：localhost:port只对运行在同一个吊舱内的容器起作用，以便相互连接，就像上面的插图中nginx如何连接到引力对象mgmt和引力对象mgmt一样。

Answer 2

对我来说，看起来你没有正确地配置哨兵，这意味着你没有提供哨兵吊舱连接到PostgreSQL吊舱和红荚的凭证。

env:
    - name: SENTRY_SECRET_KEY
      valueFrom:
        secretKeyRef:
          name: sentry-sentry
          key: sentry-secret
    - name: SENTRY_DB_USER
      value: "sentry"
    - name: SENTRY_DB_NAME
      value: "sentry"
    - name: SENTRY_DB_PASSWORD
      valueFrom:
        secretKeyRef:
          name: sentry-postgresql
          key: postgres-password
    - name: SENTRY_POSTGRES_HOST
      value: sentry-postgresql
    - name: SENTRY_POSTGRES_PORT
      value: "5432"
    - name: SENTRY_REDIS_PASSWORD
      valueFrom:
        secretKeyRef:
          name: sentry-redis
          key: redis-password
    - name: SENTRY_REDIS_HOST
      value: sentry-redis
    - name: SENTRY_REDIS_PORT
      value: "6379"
    - name: SENTRY_EMAIL_HOST
      value: "smtp"
    - name: SENTRY_EMAIL_PORT
      value: "25"
    - name: SENTRY_EMAIL_USER
      value: ""
    - name: SENTRY_EMAIL_PASSWORD
      valueFrom:
        secretKeyRef:
          name: sentry-sentry
          key: smtp-password
    - name: SENTRY_EMAIL_USE_TLS
      value: "false"
    - name: SENTRY_SERVER_EMAIL
      value: "sentry@sentry.local"

要获得更多信息，您可以参考他们配置哨兵的位置。

https://github.com/maty21/sentry-kubernetes/blob/master/sentry.yaml

Answer 3

对于豆荚之间的通信，localhost或127.0.0.1不起作用。

获取任何吊舱的IP

kubectl describe podname

使用另一个吊舱中的IP与上面的吊舱进行通信。

由于pods发生了变化，如果重新创建了Pod，那么理想情况下，应该使用库伯奈特服务，特别是clusterIP类型，用于集群内pod之间的通信。
