社区首页 >问答首页 >无法连接到PDB，Oracle 19C Linux RH7.7 ORA-01034，ORA-27101

问无法连接到PDB，Oracle 19C Linux RH7.7 ORA-01034，ORA-27101
EN

Stack Overflow用户
提问于 2020-09-15 11:15:45
回答 3查看 2.7K关注 0票数 0

所以我和甲骨文斗争了将近两天，我放弃了。我相信我检查了谷歌叔叔提供的所有解决方案。

总结一下我的问题：

  1. I已经在LinuxRH7.7上部署了Oracle19C。SID = orcl，PDBS = orclpdb和PDB
  2. I可以从主机和远程机器
  3. 连接到Oracle实例，可以更改会话集容器= PDB；更改可插拔数据库PDB打开；

但是当我尝试登录pdb时

-Sqlplus(本地主机)-甲骨文/产品/19/dbhome/bin/sqlplus系统/密码@pdb

-Impdp (本地主机)

-Sqldeveloper (远程)

​

我收到一个错误：

代码语言：javascript
复制
ERROR:ORA-01034: ORACLE not available
ORA-27101: shared memory realm does not exist
Linux-x86_64 Error: 2: No such file or directory
Additional information: 4376
Additional information: -1774770425
Process ID: 0
Session ID: 0 Serial number: 0

我的环境看起来是：

代码语言：javascript
复制
show pdbs;
    CON_ID CON_NAME                       OPEN MODE  RESTRICTED
     2 PDB$SEED                       READ ONLY  NO
     3 ORCLPDB                        MOUNTED
     4 PDB                            READ WRITE NO

$ echo $ORACLE_HOME
/oracle/product/19/dbhome
$ echo $ORACLE_SID
orcl

听众：

代码语言：javascript
复制
cat /oracle/product/19/dbhome/network/admin/listener.ora
# listener.ora Network Configuration File: /oracle/product/19/dbhome/network/admin/listener.ora
# Generated by Oracle configuration tools.

SID_LIST_LISTENER =
(SID_LIST =
(SID_DESC =
  (GLOBAL_DBNAME = orcl)
  (ORACLE_HOME = /oracle/product/19/dbhome)
  (SID_NAME = orcl)
)
(SID_DESC =
  (GLOBAL_DBNAME = orclpdb)
  (ORACLE_HOME = /oracle/product/19/dbhome)
  (SID_NAME = orclpdb)
)
(SID_DESC =
  (GLOBAL_DBNAME = pdb)
  (ORACLE_HOME = /oracle/product/19/dbhome)
  (SID_NAME = pdb)
)
)

LISTENER =
(DESCRIPTION_LIST =
(DESCRIPTION =
  (ADDRESS = (PROTOCOL = TCP)(HOST = 10.103.19.240)(PORT = 1521))
  (ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1521))
)
)

姓名：

代码语言：javascript
复制
cat /oracle/product/19/dbhome/network/admin/tnsnames.ora
ORCL=
(description=
(address_list=
 (address = (protocol = TCP)(host = 10.103.19.240)(port = 1521))
 )
(connect_data =
(service_name=orcl)
)
)
PDB=
(description=
(address_list=
 (address = (protocol = TCP)(host = 10.103.19.240)(port = 1521))
 )
(connect_data =
(service_name=pdb)
)
)

基于

代码语言：javascript
复制
cat /etc/hosts
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4

听众状态：

代码语言：javascript
复制
$ /oracle/product/19/dbhome/bin/lsnrctl start
LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 15-SEP-2020 12:11:13

Copyright (c) 1991, 2019, Oracle.  All rights reserved.

Starting /oracle/product/19/dbhome/bin/tnslsnr: please wait...

TNSLSNR for Linux: Version 19.0.0.0.0 - Production
System parameter file is /oracle/product/19/dbhome/network/admin/listener.ora
Log messages written to /oracle/diag/tnslsnr/ies-phipdb-r77/listener/alert/log.xml
Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=10.103.19.240)(PORT=1521)))
Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=EXTPROC1521)))

Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=TCP)(HOST=10.103.19.240)(PORT=1521)))
STATUS of the LISTENER
------------------------
Alias                     LISTENER
Version                   TNSLSNR for Linux: Version 19.0.0.0.0 - Production
Start Date                15-SEP-2020 12:11:13
Uptime                    0 days 0 hr. 0 min. 0 sec
Trace Level               off
Security                  ON: Local OS Authentication
SNMP                      OFF
Listener Parameter File   /oracle/product/19/dbhome/network/admin/listener.ora
Listener Log File         /oracle/diag/tnslsnr/ies-phipdb-r77/listener/alert/log.xml
Listening Endpoints Summary...
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=10.103.19.240)(PORT=1521)))
  (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=EXTPROC1521)))
Services Summary...
Service "orcl" has 1 instance(s).
  Instance "orcl", status UNKNOWN, has 1 handler(s) for this service...
Service "orclpdb" has 1 instance(s).
  Instance "orclpdb", status UNKNOWN, has 1 handler(s) for this service...
Service "pdb" has 1 instance(s).
  Instance "pdb", status UNKNOWN, has 1 handler(s) for this service...
The command completed successfully

，你知道为什么它不起作用吗？以及如何使它工作？

问候皮奥特

linux
oracle
pdb
EN

回答 3

Stack Overflow用户

发布于 2020-09-15 12:46:59

这是SID_LIST_LISTENER在listener.ora中的配置

将可插入的列表作为"SID“，意味着监听器提供这些名称，就像它们是实例一样。这就是您获得“共享领域等”的原因，因为这些实例不存在(因此启动)。

一个典型的listener.ora可能看起来像

代码语言：javascript
复制
LISTENER =
  (DESCRIPTION_LIST =
    (DESCRIPTION =
      (ADDRESS = (PROTOCOL = TCP)(HOST = localhost)(PORT = 1521))
      (ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1519))
    )
  )

SID_LIST_LISTENER19 =
  (SID_LIST =
    (SID_DESC =
      (SID_NAME = CLRExtProc)
      (ORACLE_HOME = C:\oracle\product\19)
      (PROGRAM = extproc)
      (ENVS = "EXTPROC_DLLS=ONLY:C:\oracle\product\19\bin\oraclr19.dll")
    )
  )

在您可以看到条目的地方，只需要支持主机/端口和外部程序。每个可插拔程序都会很高兴地向监听器注册，然后监听器会将可插入性作为服务提供出去。

票数 2
EN

Stack Overflow用户

发布于 2020-09-16 09:31:04

在我的Vagrant/Virtualbox环境中：

重命名listener.ora (使用默认设置)

代码语言：javascript
复制
[oracle@localhost ~]$ mv /u01/app/oracle/product/19.0.0/grid/network/admin/listener.ora /u01/app/oracle/product/19.0.0/grid/network/admin/listener.ora.1

重新启动监听器

代码语言：javascript
复制
[oracle@localhost ~]$ lsnrctl stop; lsnrctl start; lsnrctl status

LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 16-SEP-2020 11:10:41

Copyright (c) 1991, 2019, Oracle.  All rights reserved.

Connecting to (ADDRESS=(PROTOCOL=tcp)(HOST=)(PORT=1521))
The command completed successfully

LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 16-SEP-2020 11:10:41

Copyright (c) 1991, 2019, Oracle.  All rights reserved.

Starting /u01/app/oracle/product/19.0.0/dbhome_1/bin/tnslsnr: please wait...

TNSLSNR for Linux: Version 19.0.0.0.0 - Production
Log messages written to /u01/app/oracle/diag/tnslsnr/localhost/listener/alert/log.xml
Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=localhost)(PORT=1521)))

Connecting to (ADDRESS=(PROTOCOL=tcp)(HOST=)(PORT=1521))
STATUS of the LISTENER
------------------------
Alias                     LISTENER
Version                   TNSLSNR for Linux: Version 19.0.0.0.0 - Production
Start Date                16-SEP-2020 11:10:41
Uptime                    0 days 0 hr. 0 min. 0 sec
Trace Level               off
Security                  ON: Local OS Authentication
SNMP                      OFF
Listener Log File         /u01/app/oracle/diag/tnslsnr/localhost/listener/alert/log.xml
Listening Endpoints Summary...
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=localhost)(PORT=1521)))
The listener supports no services
The command completed successfully

LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 16-SEP-2020 11:10:41

Copyright (c) 1991, 2019, Oracle.  All rights reserved.

Connecting to (ADDRESS=(PROTOCOL=tcp)(HOST=)(PORT=1521))
STATUS of the LISTENER
------------------------
Alias                     LISTENER
Version                   TNSLSNR for Linux: Version 19.0.0.0.0 - Production
Start Date                16-SEP-2020 11:10:41
Uptime                    0 days 0 hr. 0 min. 0 sec
Trace Level               off
Security                  ON: Local OS Authentication
SNMP                      OFF
Listener Log File         /u01/app/oracle/diag/tnslsnr/localhost/listener/alert/log.xml
Listening Endpoints Summary...
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=localhost)(PORT=1521)))
The listener supports no services
The command completed successfully

还没有通过侦听器公开的服务！

代码语言：javascript
复制
# A database background process is responsible for registration every 30 sec,
# but we can force service registration
[oracle@localhost ~]$ echo 'alter system register;' | sqlplus / as sysdba

SQL*Plus: Release 19.0.0.0.0 - Production on Wed Sep 16 11:11:41 2020
Version 19.3.0.0.0

Copyright (c) 1982, 2019, Oracle.  All rights reserved.


Connected to:
Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.3.0.0.0

SQL>
System altered.

SQL> Disconnected from Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.3.0.0.0

哦，是的!有服务

代码语言：javascript
复制
[oracle@localhost ~]$ lsnrctl status

LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 16-SEP-2020 11:12:12

Copyright (c) 1991, 2019, Oracle.  All rights reserved.

Connecting to (ADDRESS=(PROTOCOL=tcp)(HOST=)(PORT=1521))
STATUS of the LISTENER
------------------------
Alias                     LISTENER
Version                   TNSLSNR for Linux: Version 19.0.0.0.0 - Production
Start Date                16-SEP-2020 11:10:41
Uptime                    0 days 0 hr. 1 min. 30 sec
Trace Level               off
Security                  ON: Local OS Authentication
SNMP                      OFF
Listener Log File         /u01/app/oracle/diag/tnslsnr/localhost/listener/alert/log.xml
Listening Endpoints Summary...
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=localhost)(PORT=1521)))
Services Summary...
Service "+ASM" has 1 instance(s).
  Instance "+ASM", status READY, has 1 handler(s) for this service...
Service "+ASM_DATA" has 1 instance(s).
  Instance "+ASM", status READY, has 1 handler(s) for this service...
Service "86b637b62fdf7a65e053f706e80a27ca.oradb3.private" has 1 instance(s).
  Instance "orcl", status READY, has 1 handler(s) for this service...
Service "af547de90c477ffee055000000000001.oradb3.private" has 1 instance(s).
  Instance "orcl", status READY, has 1 handler(s) for this service...
Service "orcl.oradb3.private" has 1 instance(s).
  Instance "orcl", status READY, has 1 handler(s) for this service...
Service "orclXDB.oradb3.private" has 1 instance(s).
  Instance "orcl", status READY, has 1 handler(s) for this service...
Service "pdb1.oradb3.private" has 1 instance(s).
  Instance "orcl", status READY, has 1 handler(s) for this service...
The command completed successfully

我的CDB名为: orcl.oradb3.private

代码语言：javascript
复制
# now, let's connect!
[oracle@localhost ~]$ sqlplus system/Welcome1@localhost:1521/orcl.oradb3.private

SQL*Plus: Release 19.0.0.0.0 - Production on Wed Sep 16 11:21:05 2020
Version 19.3.0.0.0

Copyright (c) 1982, 2019, Oracle.  All rights reserved.

Last Successful login time: Wed Sep 16 2020 11:20:48 +02:00

Connected to:
Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.3.0.0.0

SQL> col name for a30
SQL> r
  1* select con_id, name from v$pdbs

    CON_ID NAME
---------- ------------------------------
         2 PDB$SEED
         3 PDB1

我的PDB名为: pdb1.oradb3.private

代码语言：javascript
复制
# now, let's connect!
[oracle@localhost ~]$ sqlplus system/Welcome1@localhost:1521/pdb1.oradb3.private

SQL*Plus: Release 19.0.0.0.0 - Production on Wed Sep 16 11:24:46 2020
Version 19.3.0.0.0

Copyright (c) 1982, 2019, Oracle.  All rights reserved.

Last Successful login time: Wed Sep 16 2020 11:21:05 +02:00

Connected to:
Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.3.0.0.0


SQL> sho con_id

CON_ID
------------------------------
3
SQL>

确保可以使用EZConnect进行连接，然后修改tnsnames.ora以反映公开的服务。

祝你好运！

票数 0
EN

Stack Overflow用户

发布于 2020-09-16 18:57:08

谢谢你的重播和你花在它上的时间。

解决了在Listener.ora和tnsnames.ora中将FQDN后缀添加到PDB名称中的问题。

此外，为了远程连接，我也需要添加这个后缀。

票数 0
EN
