PAdES签名级别- Acrobat

Question

我正在使用pdfbox 3.0.0rc创建一个PADES签名，我的代码使用这个示例来创建数字签名。但是，当我用这个工具打开文档时，我无法看到Acrobat中的签名级别，尽管它能够验证我的签名。

我没有创建VRI，所以我猜测这可能是一个问题，但是如果这是验证我的签名所必需的，我不明白为什么签名显示为有效？

Adobe Acrobat签名：

​

​

/**
 * Service for automatically signing a document as part of a workflow. In this instance no user information is
 * gathered
 *
 * @param taskID
 * @param processName which will be added to the document
 * @param keyID the ID for the key used to sign the PDF document
 * @return the signed PDF document as a base 64 Encoded String
 */
@Transactional
public String signPDFService(String processID,
                             String processName,
                             String keyID,
                             ObjectData signatureImage,
                             String creator)
{
    try {



        ByteArrayOutputStream ostream = new ByteArrayOutputStream();
        //Optional<ObjectData> pdfDocumentProcessInstance = userDataRepository.findById(documents.get(0).getProcessID());

         /*List<Task> tasks = taskService.createTaskQuery()
              .taskId(taskID)
              .list();
    // Optional<ObjectData> pdfDocumentProcessInstance = userDataRepository.findById(documents.get(0).getProcessID());

    List<PDFDocument> documents = tasks.stream()
              .map(task -> {
                  String processID =  task.getProcessInstanceId();
                  Map<String, Object> variables = taskService.getVariables(task.getId());
                  PDFDocument document;
                  try {
                      document =  new PDFDocument(
                              (ArrayList) variables.get("assigneeList"),
                              (String) variables.get("unsignedPDFDocument"),
                              task.getProcessInstanceId(),
                              task.getId(),
                              (String) variables.get("name"),
                              (String) variables.get("description")
                        );
                      document.setHistory((ArrayList) variables.get("history"));
                      return document;

                } catch (IOException e) {
                    // TODO Auto-generated catch block
                    e.printStackTrace();
                    return null;
                } catch (CMSException e) {
                    // TODO Auto-generated catch block
                    e.printStackTrace();
                    return null;
                }
              })
              .collect(Collectors.toList());*/


     //Optional<ObjectData> pdfDocumentProcessInstance = userDataRepository.findById(documents.get(0).getProcessID());
        Optional<ObjectData> pdfDocumentProcessInstance = userDataRepository.findById(processID);
     if(pdfDocumentProcessInstance.isEmpty())
         throw new IOException("No process found");

        String pdfDocumentBase64String = pdfDocumentProcessInstance.get().getAttributes().get("PDFDocument");
        String extractedPDFString = pdfDocumentBase64String.replaceAll("data:application/pdf;base64,", "").replaceAll("data:;base64,", "").replaceAll("data:application/octet-stream", "");
        //String extractedPDFString = base64PDF.replaceAll("data:application/pdf;base64,", "").replaceAll("data:;base64,", "");
        InputStream stream = new ByteArrayInputStream(Base64.getDecoder().decode(extractedPDFString.getBytes()));


        //Create the date object to sign the document
        Date date = new Date();
        Calendar calendar = Calendar.getInstance();

        calendar.setTime(date);

        //Retrieve certificate chain for the PDF Signer
        String certChainPEM = kmsService.getCertChainPEM(keyID);
        X509Certificate pdfSignerCertificate = X509Utils.readCertificateChain(certChainPEM).get(0).getCertificate();

        //Create the CMS Signing Object
        ExternalSignatureCMSSignedDataGenerator cmsGenerator = new ExternalSignatureCMSSignedDataGenerator();
        ExternalSignatureSignerInfoGenerator signerGenerator = new ExternalSignatureSignerInfoGenerator(CMSSignedDataGenerator.DIGEST_SHA256, "1.2.840.10045.4.3.2");
        signerGenerator.setCertificate(pdfSignerCertificate);
        ExternalSigningSupport externalSigningSupport;
        PDDocument pdDocument = Loader.loadPDF(stream);


        //Create the PDFBox Signature Object
        PDSignature pdSignature = new PDSignature();
        pdSignature.setFilter(PDSignature.FILTER_ADOBE_PPKLITE);
        pdSignature.setSubFilter(PDSignature.SUBFILTER_ETSI_CADES_DETACHED);
        pdSignature.setLocation("Remote IS Blocks Signer");
        pdSignature.setName("IS Blocks Signer");
        pdSignature.setReason(processName);
        pdDocument.setDocumentId(calendar.getTimeInMillis());
        pdSignature.setSignDate(calendar);

        // Optional: Certify the first time signature
        // can be done only if version is at least 1.5 and if not already set
        // doing this on a PDF/A-1b file fails validation by Adobe preflight (PDFBOX-3821)
        // PDF/A-1b requires PDF version 1.4 max, so don't increase the version on such files.

        int accessPermissions = SigUtils.getMDPPermission(pdDocument);



        if (pdDocument.getVersion() >= 1.5f && accessPermissions == 0 && processName.contains("Document Certifying Key"))
        {
            logger.debug("Certifying Document");
            SigUtils.setMDPPermission(pdDocument, pdSignature, 3);
        }

        if(signatureImage != null) {
            int pageNumber = Integer.parseInt(signatureImage.getAttributes().get("page"));
            float x = Float.parseFloat(signatureImage.getAttributes().get("x"));
            float y = Float.parseFloat(signatureImage.getAttributes().get("y"));
            float width = Float.parseFloat(signatureImage.getAttributes().get("width"));
            float height = Float.parseFloat(signatureImage.getAttributes().get("height"));
            SignatureOptions signatureOptions;
            // register signature dictionary and sign interface
            signatureOptions = new SignatureOptions();
            PDFVisibleSignature pdfVisibleSignature = new PDFVisibleSignature();
            signatureOptions.setVisualSignature(pdfVisibleSignature.createVisualSignatureTemplate(
                    x,
                    y,
                    width,
                    height,
                    pdDocument,
                    pageNumber,
                    pdSignature,
                    Base64.getDecoder().decode(data.getBytes("UTF-8"))));
            signatureOptions.setPage(pageNumber);
            pdDocument.addSignature(pdSignature, null, signatureOptions);
        } else {
            pdDocument.addSignature(pdSignature);
        }







        externalSigningSupport = pdDocument.saveIncrementalForExternalSigning(ostream);

        //Create the message digest of the pre-signed PDF
        MessageDigest digest = MessageDigest.getInstance("SHA-256");
        byte[] bytes = org.apache.commons.io.IOUtils.toByteArray(externalSigningSupport.getContent());
        byte[] hashBytes = digest.digest(bytes);

        //CMS Signature
        InputStream isBytes = new ByteArrayInputStream(bytes);
        CMSProcessable input = new CMSProcessableInputStream(isBytes);
        Security.addProvider(new org.bouncycastle.jce.provider.BouncyCastleProvider());


        MessageDigest messageDigest1 = MessageDigest.getInstance("SHA-256");
        byte[] hash = messageDigest1.digest(bytes);
        byte[] bytesToSign = signerGenerator.getBytesToSign(PKCSObjectIdentifiers.data,  hash, new Date(),
                "BC");
        String encodedData = Base64.getEncoder().encodeToString(bytesToSign);

        logger.debug("Bytes to Sign:" + (Base64.getEncoder().encodeToString(bytesToSign)));
        logger.debug("Hash:" + Base64.getEncoder().encodeToString(hash));

        //Create the signature using the keyID
        //At this time only ECDSAWithSHA256 is supported
        Map<String, String> signature = kmsService.sign(keyID, encodedData);

        byte[] signedBytes = Base64.getDecoder().decode(signature.get("signature"));

        X509Certificate[] chain;

        signerGenerator.setCertificate(pdfSignerCertificate);
        signerGenerator.setSignedBytes(signedBytes);

        cmsGenerator.addSignerInf(signerGenerator);
        cmsGenerator.addCertificatesAndCRLs(X509Utils.getCertStore(signature.get("certificateChain")));
        CMSSignedData signedData = cmsGenerator.generate(new CMSProcessableByteArray(hash), false);

        //Add a RFC3161 Time Stamp
        ValidationTimeStamp validation = new ValidationTimeStamp("https://freetsa.org/tsr");
        signedData = validation.addSignedTimeStamp(signedData);

        ContentSigner nonSigner = new ContentSigner() {

        @Override
        public byte[] getSignature() {
            return signedBytes;
        }

        @Override
        public OutputStream getOutputStream() {
            return new ByteArrayOutputStream();
        }

        @Override
        public AlgorithmIdentifier getAlgorithmIdentifier() {
            return new DefaultSignatureAlgorithmIdentifierFinder().find( "SHA256WithECDSA" );
        }
        };

        CMSSignedDataGenerator gen = new CMSSignedDataGenerator();
        JcaSignerInfoGeneratorBuilder sigb = new JcaSignerInfoGeneratorBuilder(new JcaDigestCalculatorProviderBuilder().build());
        gen.addCertificate(new X509CertificateHolder(pdfSignerCertificate.getEncoded()));
        sigb.setDirectSignature( true );

        gen.addSignerInfoGenerator(sigb.build(nonSigner, new X509CertificateHolder(pdfSignerCertificate.getEncoded())));
        CMSTypedData msg = new CMSProcessableInputStream( new ByteArrayInputStream( "not used".getBytes() ) );

        CMSSignedData signedData1 = gen.generate((CMSTypedData)msg, false);
        signedData1.getEncoded();

        externalSigningSupport.setSignature(signedData.getEncoded());

        //documents.get(0).addHistoricEvent("Signed " + processName);
        //ArrayList<String> history = documents.get(0).getHistory();

        //Post Signature

        String signedPDFDocument = Base64.getEncoder().encodeToString(ostream.toByteArray());
        PDDocument newPdf1;
        newPdf1 = Loader.loadPDF(ostream.toByteArray());
        byte[] fileContent = ostream.toByteArray();

        List<PDSignature> pdfSignatures;


        pdfSignatures = newPdf1.getSignatureDictionaries();


        byte[] signatureAsBytes;

            signatureAsBytes = newPdf1.getLastSignatureDictionary().getContents( fileContent );

        byte[] signedContentAsBytes;

            signedContentAsBytes = newPdf1.getLastSignatureDictionary().getSignedContent( fileContent );

            // Now we construct a PKCS #7 or CMS.
            CMSProcessable cmsProcessableInputStream = new CMSProcessableByteArray(signedContentAsBytes);
            CMSSignedData cmsSignedData;

            cmsSignedData = new CMSSignedData(cmsProcessableInputStream, signatureAsBytes);

            Store certificatesStore = cmsSignedData.getCertificates();
            Collection<SignerInformation> signers = cmsSignedData.getSignerInfos().getSigners();
            SignerInformation signerInformation = signers.iterator().next();
            Collection matches = certificatesStore.getMatches(signerInformation.getSID());
            X509CertificateHolder certificateHolder = (X509CertificateHolder) matches.iterator().next();


            ObjectMapper mapper = new ObjectMapper();
            ArrayList<String> signatures = null;
            //signatures =  documents.get(0).getSignatures();


            for(int iCount = 0; iCount < pdfSignatures.size(); iCount++) {
            PDFSignature pdfSignature = new PDFSignature(
                    pdfSignatures.get(iCount).getName(),
                    pdfSignatures.get(iCount).getLocation(),
                    pdfSignatures.get(iCount).getSignDate().getDisplayName(Calendar.LONG_FORMAT,  java.util.Calendar.LONG, Locale.UK),
                    pdfSignatures.get(iCount).getReason(),
                    certificateHolder.getSubject().toString(),
                    certificateHolder.getIssuer().toString(),
                    Base64.getEncoder().encodeToString(certificateHolder.getEncoded()));
                    //signatures.add(mapper.writeValueAsString(pdfSignature));
                    logger.info("Signature" + mapper.writeValueAsString(pdfSignature));

            }

            Map<String, Object> variables = new HashMap<String, Object>();
           // variables.put("history", history);
            //variables.put("unsignedPDFDocument", signedPDFDocument);
            //variables.put("signatures", signatures);
            //variables.put("status", value)


            Map<String, String> pdfDocumentProcessInstanceAttributes = pdfDocumentProcessInstance.get().getAttributes();
            pdfDocumentProcessInstanceAttributes.put("PDFDocument", signedPDFDocument);
            ObjectData newpdfProcessInstance = pdfDocumentProcessInstance.get();
            newpdfProcessInstance.setAttributes(pdfDocumentProcessInstanceAttributes);
            userDataRepository.save(newpdfProcessInstance);
            newpdfProcessInstance.getHistory().add(new Date() + "Signed by:" + creator);
            System.out.println(newpdfProcessInstance.getId() + " " + newpdfProcessInstance.toString());

            newPdf1.close();
            ostream.close();


        } catch (Exception e){
            // TODO Auto-generated catch block
            e.printStackTrace();
        }

    return null;
}

Answer 1

在分析您在评论中提供的文件https://www.dropbox.com/s/srhu9raym0ozneu/document-2.pdf?dl=0时，我发现了其中的一个问题。注意到这个问题，我重新检查了您原来的https://www.dropbox.com/s/eg9uolx35sja9es/document-17%2021.08.14.pdf?dl=0，并在其中确认了这个问题，所以这个问题可能会导致您要解决的验证问题。因此，..。

您的两个示例文件(文件-17 21.08.14.pdf和文档-使用signingTime.pdf)实际上都包含同一个多版本PDF的两个连接副本，每个副本都有一个签名的Signature1，而第二个副本只包含一个更改的ID条目。添加到它们的是带有签名的Signature2的增量更新。

%PDF-1.4
...
15 0 obj
<<
/FT /Sig
...
/T (Signature1)
...
>>
endobj
...
/ID [<1952AB9C134E46B58251246E985D5C15> <7F887303DDC0ED7C37AE77403E30DFB0>]
...
%%EOF
%PDF-1.4
...
15 0 obj
<<
/FT /Sig
...
/T (Signature1)
...
>>
endobj
...
/ID [<1952AB9C134E46B58251246E985D5C15> <A57CD5B87222756EC4A096125C7E8A42>]
...
%%EOF
...
35 0 obj
<<
/FT /Sig
...
/T (Signature2)
...
>>
...
%%EOF

这个结构被打破了，尽管它不会导致错误的交叉引用(因为第一个副本和第二个副本是相同的，除了ID之外，交叉引用和startxref偏移量指向第一个副本中各自的位置)。Adobe签名验证可以对此类问题做出非常敏感的反应。

因此，您应该删除这里的第二个副本，以取得进展。

此外，正如注释中已经提到的，CMS签名容器的SignerInfo包含一个1.2.840.113549.1.9.5 signingTime签名属性。这在PAdES基线配置文件中是禁止的。
