春云流-多目的地路由( streamBridge )

Question

我有3个服务，"service-1“，它根据传递给有效负载的id值动态地路由到其他两个服务。

但是支付处理器总是路由到主题与-out-0 "spring.cloud.stream.function.bindings.processor-out-0"服务-3是永远不会被调用.

尝试过使用spring.cloud.stream.sendto.destination，它被废弃了，但它仍然是服务-3永远不会被路由

​

​

服务-1

    @Bean
    public Function<Flux<String>, Flux<Object>> processor() {
        return messageFlux -> messageFlux.flatMap(
                stringMessage -> {
                    try {
                        payload = jsonMapper.readValue(stringMessage, Map.class);
                    } catch (JsonProcessingException e) {
                        e.printStackTrace();
                    }
                    logger.info("Payment payload  :" + payload.get("id"));
                    if(payload.get("id").equalsIgnoreCase("e-payment"))
                        streamBridge.send("processor-out-0",stringMessage);
                    else
                        streamBridge.send("processor-out-1",stringMessage);
                    return Mono.just(stringMessage);
                });
    }

    @Bean
    public Consumer<String> consumer() {
        return data -> logger.info("Payment Response :" + data);
    }

服务1 application.properties

server.port = 9000
spring.application.name=payment-process
spring.cloud.function.definition=supplier;processor;consumer
spring.cloud.stream.source=processorCheck;processorEPayment
#bindings for payment processor
spring.cloud.stream.function.bindings.processor-out-0=e-payment
spring.cloud.stream.function.bindings.processor-out-1=check-payment
spring.cloud.stream.function.bindings.processor-in-0=payment-process
#bindings for response for payment processor
spring.cloud.stream.function.bindings.consumer-in-0=payment-response
#grouping
spring.cloud.stream.bindings.processor-in-0.group=check-service
spring.cloud.stream.bindings.processor-out-0.group=check-service

赛维-2

@Bean
    public Function<String,String> processorCheck() {
        return
                data ->{
                    logger.info("Data received from :" + data);
                    return "Check Payment Successful";
                };
    }

服务-2 application.properties

server.port = 9002
spring.application.name=check-service
spring.cloud.function.definition=processorCheck
spring.cloud.stream.source=processorCheck
spring.cloud.stream.bindings.processorCheck-in-0.destination=check-payment
spring.cloud.stream.bindings.processorCheck-out-0.destination=payment-response
spring.cloud.stream.bindings.processorCheck-in-0.group=check-service
spring.cloud.stream.bindings.processorCheck-out-0.group=check-service
spring.cloud.stream.function.routing.enabled=true

消费者服务-3

    @Bean
    public Function<String,String> processorEPayment() {
        return
         data ->{
                 logger.info("Data received from :" + data);
                 return "E-Payment Successful";
         };
    }

服务-3 application.properties

server.port = 9001
spring.application.name=e-payment-service
spring.cloud.function.definition=processorEPayment
#input to e-payment service topic
spring.cloud.stream.bindings.processorEPayment-in-0.destination=e-payment
spring.cloud.stream.source=processorEPayment
#output response to e-payment topic
spring.cloud.stream.bindings.processorEPayment-out-0.destination=payment-response
spring.cloud.stream.bindings.processorEPayment-in-0.group=e-payment-service
spring.cloud.stream.bindings.processorEPayment-out-0.group=e-payment-service
spring.cloud.stream.function.routing.enabled=true

Answer 1

在您的服务-1中，在第一个StreamBridge发送中，您可以这样做-- streamBridge.send("e-payment",stringMessage);第二个StreamBridge发送调用变为- streamBridge.send("check-payment",stringMessage); --它们将分别发送到主题、e-payment和check-payment。

在service-1中删除这两个属性：(它们是不必要的，可能会更改绑定的语义)。

spring.cloud.stream.function.bindings.processor-out-0=e-payment
spring.cloud.stream.function.bindings.processor-out-1=check-payment

您需要为输出绑定添加一个目的地。

spring.cloud.stream.bindings.processor-out-0.destination=payment-response

然后，使用者将使用此主题(因为您更改了对使用者的绑定以反映此主题)。
