问测试Google助手没有连接到我的对话框流Web钩子实现
EN

Stack Overflow用户

提问于 2022-04-18 17:31:20

回答 1查看 127关注 0票数 0

我已经在对话框中构建了一个简单的聊天机器人，而las周我决定在Google助手中测试聊天机器人。我已经在对话框中测试了chatbot，它与web钩子的实现相连接，并且工作正常。但是当我在google助手中测试它时，我得到和错误的回应。

谷歌助理回应

实际上，我正在使用ngrok测试web钩子的实现，并将temp放在web钩子中。当我用对话框流演示测试它时，当调用Api时，我会得到日志。但是当我和谷歌助理一起做的时候，我没有得到日志。这就像api从未被调用过一样。

我不知道我是做了什么坏事，还是没有在google助手或对话框中配置什么东西。

我正在使用dialogflow-fulfillment和actions-on-google库使用nodejs从对话框中获取帖子，并给出对话框流和Google助手的答案。

回应谷歌助理

{
  "responseMetadata": {
    "status": {
      "code": 10,
      "message": "Failed to parse Dialogflow response into AppResponse because of invalid platform response: Could not find a RichResponse or SystemIntent in the platform response for agentId: 905b630b-ec2d-4b34-b2b1-5c4012eaa2c1 and intentId: 1e2e382e-2208-4857-8a0e-7311a141d13c. WebhookStatus: code: 5\nmessage: \"Webhook call failed. Error: NOT_FOUND, State: URL_ERROR, Reason: ERROR_NOT_FOUND, HTTP status code: 404.\"\n."
    }
  }
}

调试Google助手

{
  "response": "Sorry, Shell Virtual Agent isn't responding right now. Please try again soon.",
  "expectUserResponse": false,
  "conversationToken": "EosDS2o5ck...",
  "audioResponse": "//NExAAPeD...",
  "ssmlMarkList": [],
  "debugInfo": {
    "assistantToAgentDebug": {
      "curlCommand": "curl -v 'https://api.api.ai/api/integrations/google?token=b8699f38e6954887882558306b2ef106&versionId=3' -H 'Content-Type: application/json;charset=UTF-8' -H 'Google-Actions-API-Version: 2' -H 'Authorization: 'sadsd'  -A Google-ActionsOnGoogle/1.0 -X POST -d '{\"user\":{\"locale\":\"en-US\",\"userVerificationStatus\":\"GUEST\"},\"conversation\":{\"conversationId\":\"ABwppHG-ocBDbzP3aYSkXq90WPBMb19DcQQOfKRHKsLDv4cyow4hMjLTtM26t-5gk4VICfQfef1NmOSAJqalt9dvGRzhQ7amEA\",\"type\":\"ACTIVE\",\"conversationToken\":\"[\\\"authentication-flow\\\",\\\"authentication-s3-email\\\",\\\"authentication-vars\\\",\\\"bill-my-value-high\\\"]\"},\"inputs\":[{\"intent\":\"actions.intent.TEXT\",\"rawInputs\":[{\"inputType\":\"VOICE\",\"query\":\"ed@jones.com\"}],\"arguments\":[{\"name\":\"text\",\"rawText\":\"ed@jones.com\",\"textValue\":\"ed@jones.com\"}]}],\"surface\":{\"capabilities\":[{\"name\":\"actions.capability.MEDIA_RESPONSE_AUDIO\"},{\"name\":\"actions.capability.ACCOUNT_LINKING\"},{\"name\":\"actions.capability.SCREEN_OUTPUT\"},{\"name\":\"actions.capability.AUDIO_OUTPUT\"}]},\"availableSurfaces\":[{\"capabilities\":[{\"name\":\"actions.capability.AUDIO_OUTPUT\"},{\"name\":\"actions.capability.SCREEN_OUTPUT\"},{\"name\":\"actions.capability.WEB_BROWSER\"}]}],\"requestType\":\"SIMULATOR\"}'",
      "assistantToAgentJson": "{\"user\":{\"locale\":\"en-US\",\"userVerificationStatus\":\"GUEST\"},\"conversation\":{\"conversationId\":\"ABwppHG-ocBDbzP3aYSkXq90WPBMb19DcQQOfKRHKsLDv4cyow4hMjLTtM26t-5gk4VICfQfef1NmOSAJqalt9dvGRzhQ7amEA\",\"type\":\"ACTIVE\",\"conversationToken\":\"[\\\"authentication-flow\\\",\\\"authentication-s3-email\\\",\\\"authentication-vars\\\",\\\"bill-my-value-high\\\"]\"},\"inputs\":[{\"intent\":\"actions.intent.TEXT\",\"rawInputs\":[{\"inputType\":\"VOICE\",\"query\":\"ed@jones.com\"}],\"arguments\":[{\"name\":\"text\",\"rawText\":\"ed@jones.com\",\"textValue\":\"ed@jones.com\"}]}],\"surface\":{\"capabilities\":[{\"name\":\"actions.capability.MEDIA_RESPONSE_AUDIO\"},{\"name\":\"actions.capability.ACCOUNT_LINKING\"},{\"name\":\"actions.capability.SCREEN_OUTPUT\"},{\"name\":\"actions.capability.AUDIO_OUTPUT\"}]},\"availableSurfaces\":[{\"capabilities\":[{\"name\":\"actions.capability.AUDIO_OUTPUT\"},{\"name\":\"actions.capability.SCREEN_OUTPUT\"},{\"name\":\"actions.capability.WEB_BROWSER\"}]}],\"requestType\":\"SIMULATOR\"}",
      "delegatedRequest": {
        "delegatedRequest": ""
      }
    },
    "agentToAssistantDebug": {
      "agentToAssistantJson": "{\n  \"responseMetadata\": {\n    \"status\": {\n      \"code\": 10,\n      \"message\": \"Failed to parse Dialogflow response into AppResponse because of invalid platform response: Could not find a RichResponse or SystemIntent in the platform response for agentId: 905b630b-ec2d-4b34-b2b1-5c4012eaa2c1 and intentId: 1e2e382e-2208-4857-8a0e-7311a141d13c. WebhookStatus: code: 5\\nmessage: \\\"Webhook call failed. Error: NOT_FOUND, State: URL_ERROR, Reason: ERROR_NOT_FOUND, HTTP status code: 404.\\\"\\n.\"\n    }\n  }\n}",
      "delegatedResponse": {
        "delegatedResponse": ""
      }
    },
    "sharedDebugInfoList": [
      {
        "name": "ResponseValidation",
        "debugInfo": "",
        "subDebugEntryList": [
          {
            "name": "MalformedResponse",
            "debugInfo": "Failed to parse Dialogflow response into AppResponse because of invalid platform response: Could not find a RichResponse or SystemIntent in the platform response for agentId: 905b630b-ec2d-4b34-b2b1-5c4012eaa2c1 and intentId: 1e2e382e-2208-4857-8a0e-7311a141d13c. WebhookStatus: code: 5\nmessage: \"Webhook call failed. Error: NOT_FOUND, State: URL_ERROR, Reason: ERROR_NOT_FOUND, HTTP status code: 404.\"\n..",
            "subDebugEntryList": []
          }
        ]
      }
    ],
    "conversationBuilderExecutionEventsList": []
  },
  "conversationBuilderDebugInfo": {
    "eventList": []
  },
  "visualResponse": {
    "visualElementsList": [
      {
        "displayText": {
          "content": "Sorry, Shell Virtual Agent isn't responding right now. Please try again soon."
        }
      }
    ],
    "suggestionsList": [],
    "agentLogoUrl": ""
  },
  "clientError": 0,
  "is3pResponse": true,
  "clientOperationList": [
    {
      "operationType": 7,
      "exitIndicatorPayLoad": {
        "status": 1
      }
    }
  ],
  "projectName": "",
  "renderedHtml": "",
  "previewStartTimeMicros": "1649805199475166",
  "isEmptyResponse": false,
  "agentName": "Shell Virtual Agent",
  "servingModelOutdated": false
}

GCP测井

{
  "textPayload": "MalformedResponse: Failed to parse Dialogflow response into AppResponse because of invalid platform response: Could not find a RichResponse or SystemIntent in the platform response for agentId: 905b630b-ec2d-4b34-b2b1-5c4012eaa2c1 and intentId: 1e2e382e-2208-4857-8a0e-7311a141d13c. WebhookStatus: code: 5\nmessage: \"Webhook call failed. Error: NOT_FOUND, State: URL_ERROR, Reason: ERROR_NOT_FOUND, HTTP status code: 404.\"\n.",
  "insertId": "8lq5l0fp25rsx",
  "resource": {
    "type": "assistant_action",
    "labels": {
      "version_id": "",
      "project_id": "shell-energy-ccai-poc-dev",
      "action_id": "actions.intent.TEXT"
    }
  },
  "timestamp": "2022-04-18T17:08:02.112767941Z",
  "severity": "ERROR",
  "labels": {
    "source": "JSON_RESPONSE_VALIDATION",
    "channel": "preview",
    "querystream": "GOOGLE_USER"
  },
  "logName": "projects/shell-energy-ccai-poc-dev/logs/actions.googleapis.com%2Factions",
  "trace": "projects/702646568948/traces/ABwppHG-ocBDbzP3aYSkXq90WPBMb19DcQQOfKRHKsLDv4cyow4hMjLTtM26t-5gk4VICfQfef1NmOSAJqalt9dvGRzhQ7amEA",
  "receiveTimestamp": "2022-04-18T17:08:02.122590076Z"
}

dialogflow-es-fulfillment
