在可扩展列表中使用CircleAvatar时无法修复jank

Question

我正在使用Ajay的expandable listview mentioned in this SO question。这很好，但是当我将它修改为包含FutureBuilder以加载CircleAvatar时，当我折叠列表时，它会导致jank。

1. 当我单击向下箭头时，它最初会展开并显示person图标，因为图像没有加载。这很好，

，

1. ，然后加载图像，将person图标替换为CircleAvatar中的实际配置文件图像。这也很好。
2. ，但是当我单击向上箭头来折叠列表时，配置文件图像将被人图标替换为秒的分数，这将导致jank.

。

请看附图(很抱歉，分辨率差，使用一些在线转换器生成)。

​

​

我不明白为什么CircleAvatar会再次下载配置文件图像。为了让它记住状态，我尝试将它封装到一个StatefulCircleAvatar中，但这也不起作用。

这是我的代码：

import 'package:flutter/foundation.dart';
import 'package:flutter/material.dart';

void main() {
  runApp(MaterialApp(home: Home()));
}

class Home extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return Scaffold(
      backgroundColor: Colors.grey,
      appBar: AppBar(
        title: Text("Expandable List"),
        backgroundColor: Colors.redAccent,
      ),
      body: ListView.builder(
        itemBuilder: (BuildContext context, int index) {
          return ExpandableListView(title: "Title $index");
        },
        itemCount: 5,
      ),
    );
  }
}

class ExpandableListView extends StatefulWidget {
  final String title;

  const ExpandableListView({Key? key, required this.title}) : super(key: key);

  @override
  _ExpandableListViewState createState() => _ExpandableListViewState();
}

class _ExpandableListViewState extends State<ExpandableListView> {
  bool expandFlag = false;
  List<String>? _cachedUsers;

  @override
  Widget build(BuildContext context) {
    return Container(
      margin: EdgeInsets.symmetric(vertical: 1.0),
      child: Column(
        children: <Widget>[
          Container(
            color: Colors.blue,
            padding: EdgeInsets.symmetric(horizontal: 5.0),
            child: Row(
              mainAxisAlignment: MainAxisAlignment.spaceBetween,
              children: <Widget>[
                IconButton(
                    icon: Container(
                      height: 50.0,
                      width: 50.0,
                      decoration: const BoxDecoration(
                        color: Colors.orange,
                        shape: BoxShape.circle,
                      ),
                      child: Center(
                        child: Icon(
                          expandFlag ? Icons.keyboard_arrow_up : Icons.keyboard_arrow_down,
                          color: Colors.white,
                          size: 20.0,
                        ),
                      ),
                    ),
                    onPressed: () {
                      setState(() {
                        expandFlag = !expandFlag;
                        if(expandFlag) _cachedUsers = null;
                      });
                    }),
                Text(
                  widget.title,
                  style: TextStyle(fontWeight: FontWeight.bold, color: Colors.white),
                )
              ],
            ),
          ),
          ExpandableContainer(
              expanded: expandFlag,
              child:
                (expandFlag && _cachedUsers == null) ?
                    FutureBuilder<List<String>>(
                      future: getMyusers(),
                      builder: (context, snapshot) {
                        if (!snapshot.hasData ||
                            snapshot.connectionState == ConnectionState.waiting) {

                          return Container(
                              height: 200,
                              width: 200,
                              child: Center(child: CircularProgressIndicator()));
                        }
                        if (snapshot.hasError) {
                          return Container(
                              height: 200,
                              width: 200,
                              child: Center(child: Text(snapshot.error.toString())));
                        }
                        _cachedUsers =  snapshot.data!;
                        return ListView.builder(
                          controller: ScrollController(),
                          itemCount: _cachedUsers!.length,
                          itemBuilder: (context, index) {
                            return Container(
                              decoration:
                              BoxDecoration(border: Border.all(width: 1.0, color: Colors.white), color: Colors.black),
                              child: ListTile(
                                title: Text(
                                  _cachedUsers![index],
                                  style: TextStyle(fontWeight: FontWeight.bold, color: Colors.white),
                                ),
                                leading: StatefulCircleAvatar(userid:10),
                              ),
                            );
                          },
                        );
                      },
                    )
                    :
                    ListView.builder(
                      controller: ScrollController(),
                      itemCount:
                      _cachedUsers==null?0:_cachedUsers!.length,
                      itemBuilder: (context, index) {
                        return ListTile(
                          title: Text(
                            _cachedUsers![index],
                            style: TextStyle(fontWeight: FontWeight.bold, color: Colors.white),
                          ),
                          leading:// getCircleAvatar(24,NetworkImage("https://lh3.googleusercontent.com/a/AATXAJxaVweFMPZXdbMuuwNAkqwdbw15IK75dYGjRHp6=s96-c"), Colors.amber,),
                          StatefulCircleAvatar(userid:10),
                        );
                      },
                    )
          )
        ],
      ),
    );
  }

  Future<List<String>> getMyusers() async{
    await Future.delayed(Duration(seconds: 1 ));
    return [for(int i=0; i<10; i++) 'user $i'];
  }
}

class ExpandableContainer extends StatelessWidget {
  final bool expanded;
  final double collapsedHeight;
  final double expandedHeight;
  final Widget child;

  ExpandableContainer({
    required this.child,
    this.collapsedHeight = 0.0,
    this.expandedHeight = 300.0,
    this.expanded = true,
  });

  @override
  Widget build(BuildContext context) {
    double screenWidth = MediaQuery.of(context).size.width;
    return AnimatedContainer(
      duration: Duration(milliseconds: 500),
      curve: Curves.easeInOut,
      width: screenWidth,
      height: expanded ? expandedHeight : collapsedHeight,
      child: Container(
        child: child,
        decoration: BoxDecoration(border: Border.all(width: 1.0, color: Colors.blue)),
      ),
    );
  }
}

class StatefulCircleAvatar extends StatefulWidget {
  int userid;

  StatefulCircleAvatar({required this.userid});

  @override
  _StatefulCircleAvatarState createState() => _StatefulCircleAvatarState();
}

class _StatefulCircleAvatarState extends State<StatefulCircleAvatar> with AutomaticKeepAliveClientMixin<StatefulCircleAvatar>{
  bool get wantKeepAlive => true;
  bool _checkLoading = true;
  NetworkImage? myImage;
  @override
  void initState() {
    getProfilepicUrl(widget.userid).then((value) {
      myImage = NetworkImage(value);
      myImage!.resolve(ImageConfiguration()).addListener(ImageStreamListener ( (_, __) {
        if (mounted) {
          setState(() {
            _checkLoading = false;
          });
        }
      }) as ImageStreamListener);
    });
  }
  Widget? ca;
  @override
  Widget build(BuildContext context) {
    print('sfca build called $_checkLoading');
    return _checkLoading == true ? CircleAvatar(
        child: personIcon) : CircleAvatar(
      backgroundImage: myImage,);  }

  Future<String> getProfilepicUrl(int userid) async{
    await Future.delayed(Duration(seconds: 1 ));
    print('getprofilepicurl called');
    return "https://lh3.googleusercontent.com/a/AATXAJxaVweFMPZXdbMuuwNAkqwdbw15IK75dYGjRHp6=s96-c";
  }

  Icon personIcon = const Icon(Icons.person);
}

Answer 1

UPD:将实际修复添加到所提问题中，但我仍然建议使用我在底部建议的技术。

特别是ListView和ListView.builder只呈现可见区域的小部件。若要保留AutomaticKeepAliveClientMixin.子级的状态，请使用ListView

您可以在这里试用以下代码：https://dartpad.dev/?id=7bef8a79f16bfb8259cf2204e3694822

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      theme: ThemeData.dark().copyWith(
        scaffoldBackgroundColor: darkBlue,
      ),
      debugShowCheckedModeBanner: false,
      home: Scaffold(
        body: ListView.builder(
          itemBuilder: (context, index) => MyStatefulWidget(index: index),
          itemCount: 10,
        ),
      ),
    );
  }
}

class MyStatefulWidget extends StatefulWidget {
  const MyStatefulWidget({required this.index, Key? key}) : super(key: key);

  final int index;

  @override
  State<MyStatefulWidget> createState() => _MyStatefulWidgetState();
}

class _MyStatefulWidgetState extends State<MyStatefulWidget> with AutomaticKeepAliveClientMixin {

  @override
  void initState() {
    super.initState();
    // Will only be called once, because the widget
    // saves its state even when not visible in ListView
    print("init state called at: ${widget.index}");
  }

  @override
  Widget build(BuildContext context) {
    super.build(context);
    return Container(
      height: 400,
      child: Text("My Statful Widget ${widget.index + 1}"),
    );
  }

  @override
  bool get wantKeepAlive => true;
}

旧答案如下：

这可能是因为您的FutureBuilder在状态更改时多次调用函数getMyusers()。你能做的就是：

在_ExpandableListViewState:中创建一个新变量

late Future<List<String>> _myFutureUsers;

1. 在init状态下为其赋值，以确保只调用一次：

  @override
  void initState() {
    super.initState();
    _myFutureUsers = getMyusers()
  }

1. 用新变量

替换FutureBuilder中的未来

    FutureBuilder<List<String>>(
                          future: _myFutureUsers,
                          ...
    )
