不使用机车JS的GSAP ScrollTrigger动画(直到调整窗口大小)

Question

我在我的站点上有使用ScrollTrigger的部分。一旦我实现了Locomotive JS，我所有的ScrollTrigger动画都停止工作了。

我在论坛上看到，当update() ScrollTrigger正在滚动时，您需要使用Locomotive。我实现了这一点，但没有看到任何结果。

然后，我调整了窗口和我的ScrollTrigger动画的大小，它们开始工作。

简而言之，动画会在调整大小时触发，而不会在页面加载时触发。

我已经实现了update()，也尝试过refresh()，但没有成功。

Demo (这里也有小提琴表演的问题)：

​

$(function() {

  gsap.registerPlugin(ScrollTrigger);

  function animateFrom(elem, direction) {
    direction = direction || 1;

    var x = 0, y = direction * 100;
    if(elem.classList.contains("gsap_reveal--fromLeft")) {
      x = -100;
      y = 0;
    } else if (elem.classList.contains("gsap_reveal--fromRight")) {
      x = 100;
      y = 0;
    }

    elem.style.transform = "translate(" + x + "px, " + y + "px)";
    elem.style.opacity = "0";

    gsap.fromTo(elem, { x: x, y: y, autoAlpha: 0 }, {
      duration: 2,
      x: 0,
      y: 0,
      autoAlpha: 1,
      ease: "expo",
      overwrite: "auto"
    });

  }

  function hide(elem) {
    gsap.set(elem, { autoAlpha: 0 });
  }

  gsap.utils.toArray(".gsap_reveal").forEach(function(elem) {
    hide(elem); // assure that the element is hidden when scrolled into view
    ScrollTrigger.create({
      trigger: elem,
      onEnter: function() { animateFrom(elem) },
      onEnterBack: function() { animateFrom(elem, -1) },
      onLeave: function() { hide(elem) } // assure that the element is hidden when scrolled into view
    });
  });

    const pageContainer = document.querySelector("[data-scroll-container]");

    const scroll = new LocomotiveScroll({
      el: pageContainer,
      smooth: true
    });


    // each time locomotive Scroll updates, tell ScrollTrigger to update too (sync positioning)
    scroll.on(pageContainer, ScrollTrigger.update);

    // tell ScrollTrigger to use these proxy methods for the ".data-scroll-container" element since Locomotive Scroll is hijacking things
    ScrollTrigger.scrollerProxy(pageContainer, {
      scrollTop(value) {
        return arguments.length ? scroll.scrollTo(value, 0, 0) : scroll.scroll.instance.scroll.y;
      }, // we don't have to define a scrollLeft because we're only scrolling vertically.
      getBoundingClientRect() {
        return {top: 0, left: 0, width: window.innerWidth, height: window.innerHeight};
      }
    });

    window.addEventListener("load", function (event) {
      ScrollTrigger.refresh();
    });

    ScrollTrigger.addEventListener("refresh", () => scroll.update());
    ScrollTrigger.refresh();


});

.hero {
  min-height: 1000px;
  background: lightblue;
  display: flex;
  align-items: center;
}

.textImageRepeater {
  overflow: hidden;
  padding: 120px 0 160px 0;
}
.textImageRepeater__intro {
  margin-bottom: 66px;
}
.textImageRepeater__layout--row {
  flex-direction: row !important;
}
.textImageRepeater__layout--rowReverse {
  flex-direction: row-reverse !important;
}
.textImageRepeater__item {
  display: flex;
  align-items: center;
  justify-content: center;
  flex-direction: column;
  padding-top: 70px;
  justify-content: space-between;
}
.textImageRepeater__header {
  margin: 17px 0;
}
.textImageRepeater__graphic {
  margin: 0;
}
.textImageRepeater__text, .textImageRepeater__graphic {
  flex-basis: 50%;
}
.textImageRepeater__text {
  max-width: 500px;
}

.c-scrollbar_thumb{
  background-color: #5D209F!important;
  width: 7px;
  margin: 2px;
  opacity: 1;
  border-radius: unset;
  mix-blend-mode: multiply;
}

<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.0.2/dist/css/bootstrap.min.css" rel="stylesheet" integrity="sha384-EVSTQN3/azprG1Anm3QDgpJLIm9Nao0Yz1ztcQTwFspd3yD65VohhpuuCOmLASjC" crossorigin="anonymous">

<link href="https://cdn.jsdelivr.net/npm/locomotive-scroll@4.1.3/dist/locomotive-scroll.min.css" rel="stylesheet">

<script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/3.6.0/jquery.min.js" integrity="sha512-894YE6QWD5I59HgZOGReFYm4dnWc1Qt5NtvYSaNcOP+u1T9qYdvdihz0PPSiiqn/+/3e7Jo4EaG7TubfWGUrMQ==" crossorigin="anonymous" referrerpolicy="no-referrer"></script>

<script src="https://cdn.jsdelivr.net/npm/locomotive-scroll@4.1.3/dist/locomotive-scroll.min.js"></script>

<script src="https://cdnjs.cloudflare.com/ajax/libs/gsap/3.9.1/gsap.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/gsap/3.9.1/ScrollTrigger.min.js"></script>

<div data-scroll-container>
  <div data-scroll-section>

    <section class="hero">
      <div class="container">
        <div class="row justify-content-center justify-content-xl-between">
          <div class="col-12 col-md-10 col-lg-9 col-xl-5">
            <div class="hero__text text-center text-xl-start">
              <h1 class="hero__title" data-scroll data-scroll-speed="2">Title</h1>
            </div>
          </div>
        </div>
      </div>
    </section>

    <section class="textImageRepeater">
      <div class="container">
        <div class="row">
          <div class="col-12">

            <div class="textImageRepeater__item textImageRepeater__layout--row">
              <div class="textImageRepeater__text text-center text-md-start gsap_reveal gsap_reveal--fromRight">
                <div class="textImageRepeater__copy">
                  <h2>Header</h2>
                  <p>Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.</p>
                </div>
              </div>
              <div class="textImageRepeater__graphic text-center gsap_reveal gsap_reveal--fromLeft">
                <img class="textImageRepeater__image" src="https://picsum.photos/200/300" alt="placeholder-image" loading="lazy">
              </div>
            </div>

            <div class="textImageRepeater__item textImageRepeater__layout--rowReverse">
              <div class="textImageRepeater__text text-center text-md-start gsap_reveal gsap_reveal--fromRight">
                <div class="textImageRepeater__copy">
                  <h2>Header</h2>
                  <p>Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.</p>
                </div>
              </div>
              <div class="textImageRepeater__graphic text-center gsap_reveal gsap_reveal--fromLeft">
                <img class="textImageRepeater__image" src="https://picsum.photos/200/300" alt="placeholder-image" loading="lazy">
              </div>
            </div>

          </div>
        </div>
      </div>
    </section>

  </div>
</div>

​

测试1

我意识到，如果我评论掉所有的locomotive js并运行：

​

$(window).on('scroll', function() {
  console.log("test");
});

​

logs会显示出来，但当locomotive处于活动状态时就不会显示了。

不确定这是否表明出了什么问题？

测试2

在我的片段末尾，我运行了下面的代码，以检查refresh()是否正在运行，并且它正在返回else语句。再说一遍，不知道为什么。

​

if (ScrollTrigger.refresh()){
  console.log("true");
} else{
  console.log("false");
}

​

重新创建的步骤：

1. 打开这把小提琴
2. 将输出框扩大到宽的(即1300px)
3. 拨弄小提琴
4. 向下滚动，您将看到没有加载的元素
5. 将输出框调整为较小的大小
6. 现在出现scrollTrigger动画

这里有一个gif展示了这个问题：

​

​

Answer 1

这就是我一直在努力让动画运行的东西。

1.让ScrollTrigger知道新的滚轮.

由于您使用的是机车卷轴，这意味着删除了ScrollTrigger所基于的本地滚动。所以我们通过这样做把它带回来

ScrollTrigger.create({
    scroller: "[data-scroll-container]" // this is what you're missing
    // your other options
});

阅读docs for ScrollTrigger > scroller

2.最后分配ScrollTrigger .

我不太确定，但原因可能很简单，因为一旦设置了整个滚动系统，就需要分配tweens。

// init Locomotive
// ...

// create ScrollTrigger
gsap.utils.toArray(".gsap_reveal").forEach(function(elem) {
    hide(elem); // assure that the element is hidden when scrolled into view
    ScrollTrigger.create({
      scroller: "[data-scroll-container]",
      trigger: elem,
      onEnter: function() { animateFrom(elem) },
      onEnterBack: function() { animateFrom(elem, -1) },
      onLeave: function() { hide(elem) } // assure that the element is hidden when scrolled into view
    });
  });

请参阅JSFiddle
