创建按行连接的css圆圈

Question

我需要做这样的滑块，它是由一条线连接的三个圆圈，每个圆圈下面都有一个描述：

​

​

但现在我只有这个：

​

​

这就是我用来做的代码：

            <div
              class="
                text-center
                my-5
                px-5
                d-flex
                align-items-center
                justify-content-between
                slider-container
              "
            >
              <div class="slider-item">
                <i
                  class="
                    icon-circle
                    fs-16 fs-md-20
                    d-inline-block
                    text-gray-300
                  "
                ></i>
                <p class="m-0 font-RobotoBold1 fs-10 fs-md-12 mt-2">
                  Selecciona <br />
                  cantidad
                </p>
              </div>
              <div>
                <i
                  class="
                    icon-circle
                    fs-16 fs-md-20
                    d-inline-block
                    text-gray-300
                  "
                ></i>
                <p class="m-0 font-RobotoBold1 fs-10 fs-md-12 mt-2">
                  Selecciona <br />
                  destino
                </p>
              </div>
              <div>
                <i
                  class="
                    icon-circle
                    fs-16 fs-md-20
                    d-inline-block
                    text-gray-300
                  "
                ></i>
                <p class="m-0 font-RobotoBold1 fs-10 fs-md-12 mt-2">
                  Confirma <br />
                  transferencia
                </p>
              </div>
            </div>

这是css代码：

.slider-container {
  position: relative;
  display: flex;
  justify-content: space-between;
  align-items: center;
  padding: 1em;
  overflow: hidden;
}

.slider-container::before {
  position: absolute;
  top: calc(50% - 20px);
  right: 0;
  left: 0;
  Content: "";
  Background-color: grey;
  height: 1px;
  z-index: -1;
}

有人知道如何在圆圈后面划出这条线，而这条线并不会超越他们？

Answer 1

Sidenote:这就是为什么我永远不会使用尾翼或类似的东西。你不需要它，它完全破坏了HTML。

现在，将您拥有的标记与下面的标记进行比较--这是( a)要简洁得多，b)只使用单个CSS类，c)使用适当的语义元素。

它也适用于2或4或7个项目。当然，它需要一些细化的大小和颜色的活动圈，但这应该是一个简单的调整对你。

此解决方案的唯一限制是，您的页面背景色需要是坚实的，并与::after元素的背景色相匹配。

​

document.querySelectorAll('.steplist').forEach(steplist => {
  steplist.addEventListener('click', function(event) {
    if (event.target.nodeName !== 'LI') return;
    const items = event.target.closest('.steplist').querySelectorAll('li');
    for (const item of items) {
      item.classList.toggle('active', item === event.target);
    }
  });
});

*, ::after, ::before { box-sizing: border-box; }

.steplist {
  border-top: 2px solid #ccc;
  display: inline-flex;
  font-family: 'Gill Sans', 'Gill Sans MT', Calibri, 'Trebuchet MS', sans-serif;
  list-style-type: none;
  gap: 7em;
  margin: 0;
  padding: 0;
  --circle-radius: 8px;
}

.steplist li {
  color: #999;
  cursor: pointer;
  padding: calc(5px + var(--circle-radius)) 0 0;
  margin: 0;
  position: relative;
  text-align: center;
}

.steplist li::before {
  background-color: #ccc;
  border-radius: 50%;
  content: '';
  position: absolute;
  height: calc(2 * var(--circle-radius));
  width: calc(2 * var(--circle-radius));
  top: 0;
  left: 50%;
  transform: translate(-50%, -50%);
  transition: all 0.3s ease;
}

.steplist .active {
  color: black;
}

.steplist .active::before {
  background-color: green;
  box-shadow: 0 0 0 3px rgba(0,255,0,.25);
}

.steplist li:first-child::after {
  background-color: white;
  content: '';
  position: absolute;
  height: 2px;
  width: 100%;
  top: -2px;
  left: calc(-50% - var(--circle-radius));
}

.steplist li:last-child::after {
  background-color: white;
  content: '';
  position: absolute;
  height: 2px;
  width: 100%;
  top: -2px;
  left: calc(50% + var(--circle-radius));
}

.circle-big {
  --circle-radius: 12px;
}

<ol class="steplist">
  <li>Point 1<br>whatever</li>
  <li>Point 2<br>whatever</li>
  <li>Point 3<br>whatever</li>
</ol>

<br><br><br>

<ol class="steplist circle-big">
  <li>Point 1<br>whatever</li>
  <li>Point 2<br>whatever</li>
  <li>Point 3<br>whatever</li>
  <li>Point 4<br>whatever</li>
</ol>

​

Answer 2

最后，我用这段代码解决了这个问题，我添加了自定义类，这样您就可以理解这些类，在滑块容器中，公式'top: calc(50% -22 px )‘中的px可以根据屏幕的大小而改变。：

​

/* slider css code */

.slider-container {
  position: relative;
  display: flex;
  justify-content: space-between;
  align-items: center;
  padding: 1em;
  overflow: hidden;
}

.slider-container::before {
  position: absolute;
  top: calc(50% - 22px);
  right: 65px;
  left: 65px;
  content: "";
  background-color: #d8d8d8;
  height: 1px;
  z-index: -1;
}

@media (max-width: 768px) {
  .slider-container::before {
    top: calc(50% - 22px);
    right: 60px;
    left: 60px;
  }
}


/* this are custom css classes we use at work */

.wi-12 {
  width: 12px;
}

.he-12 {
  height: 12px;
}

.wi-24 {
  width: 24px;
}

.he-24 {
  height: 24px;
}

@media (min-width: 768px) {
  .wi-md-20 {
    width: 20px;
  }
  .he-md-20 {
    height: 20px;
  }
  .wi-md-30 {
    width: 30px;
  }
  .he-md-30 {
    height: 30px;
  }
  .wi-md-100 {
    width: 100px;
  }
}

.wi-70 {
  width: 70px;
}

.bg-green-700 {
  background-color: #00bf79;
}

.bg-gray-300 {
  background-color: #bababa;
}

.bor-rounded-full {
  border-radius: 50%;
}

.font-Roboto {
  font-family: "Roboto";
}

.fs-10 {
  font-size: 10px;
}

.fs-md-12 {
  font-size: 12px;
}

<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.1.3/dist/css/bootstrap.min.css" rel="stylesheet" />

<div class="
                text-center
                mt-md-4
                px-4
                d-flex
                align-items-center
                justify-content-between
                slider-container
                mb-md-3
              ">
  <div class="slider-item wi-70 wi-md-100">
    <div class="
                    wi-24
                    he-24
                    wi-md-30
                    he-md-30
                    bor-rounded-full
                    d-inline-flex
                    justify-content-center
                    align-items-center
                  " style="
                   background: rgba(0, 191, 121, 0.3);
                  ">
      <div class="wi-12 he-12 wi-md-20 he-md-20 bg-green-700 bor-rounded-full d-inline-block"></div>
    </div>
    <p class="m-0 font-Roboto fs-10 fs-md-12 mt-2">
      Selecciona <br /> cantidad
    </p>
  </div>
  <div class="slider-item wi-70 wi-md-100">
    <div class="
                    wi-24
                    he-24
                    wi-md-30
                    he-md-30
                    bor-rounded-full
                    d-inline-flex
                    justify-content-center
                    align-items-center
                  ">
      <div class="wi-12 he-12 wi-md-20 he-md-20 bg-gray-300 bor-rounded-full d-inline-block"></div>
    </div>
    <p class="m-0 font-Roboto fs-10 fs-md-12 mt-2">
      Selecciona <br /> destino
    </p>
  </div>
  <div class="slider-item wi-70 wi-md-100">
    <div class="
                    wi-24
                    he-24
                    wi-md-30
                    he-md-30
                    bor-rounded-full
                    d-inline-flex
                    justify-content-center
                    align-items-center
                  ">
      <div class="wi-12 he-12 wi-md-20 he-md-20 bg-gray-300 bor-rounded-full d-inline-block"></div>
    </div>
    <p class="m-0 font-Roboto fs-10 fs-md-12 mt-2">
      Confirma <br /> transferencia
    </p>
  </div>
</div>

​
