PostgreSQL Bitmap scan 和 Index scan 优化一个SQL ，结果非常不一样！

test=#
test=# DROP TABLE IF EXISTS users CASCADE;
NOTICE:  table "users" does not exist, skipping
   bigserial PRIMARY KEY,
    user_id    bigint NOT NULL,
    status     text NOT NULL,
    created_at timestamptz NOT NULL,
    amount     numeric
);DROP TABLE
test=#
test=# CREATE TABLE users (
test(#     user_id bigint PRIMARY KEY,
test(#     user_name text
test(# );
CREATE TABLE
test=#
test=# INSERT INTO users
test-# SELECT id, 'user_' || id
test-# FROM generate_series(1, 1000) id;
INSERT 0 1000
test=#
test=#
test=# DROP TABLE IF EXISTS orders;
NOTICE:  table "orders" does not exist, skipping
DROP TABLE
test=#
test=# CREATE TABLE orders (
test(#     order_id   bigserial PRIMARY KEY,
test(#     user_id    bigint NOT NULL,
test(#     status     text NOT NULL,
test(#     created_at timestamptz NOT NULL,
test(#     amount     numeric
test(# );
CREATE TABLE
test=#
test=#
test=#
test=# INSERT INTO orders (user_id, status, created_at, amount)
test-# SELECT
test-#     (random() * 999 + 1)::int,
test-#     CASE WHEN random() < 0.7 THEN 'PAID' ELSE 'NEW' END,
test-#     now() - (random() * interval '30 days'),
test-#     random() * 1000
test-# FROM generate_series(1, 1000000);
INSERT 0 1000000
test=#
test=#
test=# \timing
Timing is on.
test=# EXPLAIN (ANALYZE, BUFFERS)
test-# SELECT
test-#     u.user_name,
test-#     count(*)
test-# FROM
test-#     orders o
test-# JOIN users u ON o.user_id = u.user_id
test-# WHERE
test-#     o.user_id = 42
test-#     AND o.status = 'PAID'
test-# GROUP BY u.user_name;
                                                                         QUERY PLAN

------------------------------------------------------------------------------------------------------------------------------------------
------------------
 Finalize GroupAggregate  (cost=16619.87..16622.31 rows=1 width=16) (actual time=27.053..29.310 rows=1.00 loops=1)
   Group Key: u.user_name
   Buffers: shared hit=9382
   ->  Gather Merge  (cost=16619.87..16622.29 rows=2 width=16) (actual time=27.006..29.271 rows=3.00 loops=1)
         Workers Planned: 2
         Workers Launched: 2
         Buffers: shared hit=9382
         ->  Partial GroupAggregate  (cost=15619.84..15622.03 rows=1 width=16) (actual time=22.965..23.018 rows=1.00 loops=3)
               Group Key: u.user_name
               Buffers: shared hit=9382
               ->  Sort  (cost=15619.84..15620.57 rows=291 width=8) (actual time=20.692..21.811 rows=235.67 loops=3)
                     Sort Key: u.user_name
                     Sort Method: quicksort  Memory: 25kB
                     Buffers: shared hit=9382
                     Worker 0:  Sort Method: quicksort  Memory: 25kB
                     Worker 1:  Sort Method: quicksort  Memory: 25kB
                     ->  Nested Loop  (cost=0.28..15607.93 rows=291 width=8) (actual time=0.116..19.546 rows=235.67 loops=3)
                           Buffers: shared hit=9366
                           ->  Parallel Seq Scan on orders o  (cost=0.00..15596.00 rows=291 width=8) (actual time=0.041..12.387 rows=235.6
7 loops=3)
                                 Filter: ((user_id = 42) AND (status = 'PAID'::text))
                                 Rows Removed by Filter: 333098
                                 Buffers: shared hit=9346
                           ->  Materialize  (cost=0.28..8.30 rows=1 width=16) (actual time=0.005..0.010 rows=1.00 loops=707)
                                 Storage: Memory  Maximum Storage: 17kB
                                 Buffers: shared hit=20
                                 ->  Index Scan using users_pkey on users u  (cost=0.28..8.29 rows=1 width=16) (actual time=0.027..0.037 r
ows=1.00 loops=3)
                                       Index Cond: (user_id = 42)
                                       Index Searches: 3
                                       Buffers: shared hit=20
 Planning:
   Buffers: shared hit=60
 Planning Time: 0.257 ms
 Execution Time: 29.372 ms
(33 rows)

Time: 30.414 ms
test=#
test=#
test=#
test=#
test=# CREATE INDEX idx_orders_user
test-# ON orders(user_id);
CREATE INDEX
Time: 251.459 ms
test=#
test=# CREATE INDEX idx_orders_status
test-# ON orders(status);
CREATE INDEX
Time: 302.121 ms
test=#
test=# EXPLAIN (ANALYZE, BUFFERS)
SELECT
    u.user_name,
    count(*)
FROM
    orders o
JOIN users u ON o.user_id = u.user_id
WHERE
    o.user_id = 42
    AND o.status = 'PAID'
GROUP BY u.user_name;
                                                                 QUERY PLAN

------------------------------------------------------------------------------------------------------------------------------------------
--
 HashAggregate  (cost=2929.47..2929.48 rows=1 width=16) (actual time=20.371..20.414 rows=1.00 loops=1)
   Group Key: u.user_name
   Batches: 1  Memory Usage: 32kB
   Buffers: shared hit=930 read=3
   ->  Nested Loop  (cost=12.35..2925.97 rows=699 width=8) (actual time=0.465..15.479 rows=707.00 loops=1)
         Buffers: shared hit=930 read=3
         ->  Index Scan using users_pkey on users u  (cost=0.28..8.29 rows=1 width=16) (actual time=0.017..0.029 rows=1.00 loops=1)
               Index Cond: (user_id = 42)
               Index Searches: 1
               Buffers: shared hit=3
         ->  Bitmap Heap Scan on orders o  (cost=12.08..2910.69 rows=699 width=8) (actual time=0.423..6.631 rows=707.00 loops=1)
               Recheck Cond: (user_id = 42)
               Filter: (status = 'PAID'::text)
               Rows Removed by Filter: 279
               Heap Blocks: exact=927
               Buffers: shared hit=927 read=3
               ->  Bitmap Index Scan on idx_orders_user  (cost=0.00..11.90 rows=997 width=0) (actual time=0.183..0.188 rows=986.00 loops=1
)
                     Index Cond: (user_id = 42)
                     Index Searches: 1
                     Buffers: shared read=3
 Planning:
   Buffers: shared hit=29 read=2
 Planning Time: 0.383 ms
 Execution Time: 20.485 ms
(24 rows)

Time: 21.646 ms
test=#
test=#
test=#
test=# DROP INDEX idx_orders_user;
DROP INDEX
Time: 1.940 ms
test=# DROP INDEX idx_orders_status;
DROP INDEX
Time: 1.755 ms
test=#
test=# CREATE INDEX idx_orders_user_status
test-# ON orders (user_id, status);
CREATE INDEX
Time: 331.547 ms
test=#
test=#
test=# EXPLAIN (ANALYZE, BUFFERS)
test-# SELECT
test-#     u.user_name,
test-#     count(*)
test-# FROM
test-#     orders o
test-# JOIN users u ON o.user_id = u.user_id
test-# WHERE
test-#     o.user_id = 42
test-#     AND o.status = 'PAID'
test-# GROUP BY u.user_name;
                                                                        QUERY PLAN

------------------------------------------------------------------------------------------------------------------------------------------
----------------
 HashAggregate  (cost=37.18..37.19 rows=1 width=16) (actual time=13.835..13.870 rows=1.00 loops=1)
   Group Key: u.user_name
   Batches: 1  Memory Usage: 32kB
   Buffers: shared hit=4 read=3
   ->  Nested Loop  (cost=0.70..33.69 rows=699 width=8) (actual time=0.065..10.329 rows=707.00 loops=1)
         Buffers: shared hit=4 read=3
         ->  Index Scan using users_pkey on users u  (cost=0.28..8.29 rows=1 width=16) (actual time=0.012..0.023 rows=1.00 loops=1)
               Index Cond: (user_id = 42)
               Index Searches: 1
               Buffers: shared hit=3
         ->  Index Only Scan using idx_orders_user_status on orders o  (cost=0.42..18.41 rows=699 width=8) (actual time=0.038..3.787 rows=
707.00 loops=1)
               Index Cond: ((user_id = 42) AND (status = 'PAID'::text))
               Heap Fetches: 0
               Index Searches: 1
               Buffers: shared hit=1 read=3
 Planning:
   Buffers: shared hit=22 read=1
 Planning Time: 0.212 ms
 Execution Time: 13.919 ms
(19 rows)

Time: 14.738 ms
test=#
test=#

 Bitmap index

idx_orders_user
   ↓
Bitmap Index Scan
   ↓  (构建 bitmap)
Bitmap Heap Scan
   ↓  (回表 + Filter status)
Nested Loop
   ↓
HashAggregate

index scan

idx_orders_user_status
   ↓
Index Only Scan
   ↓
Nested Loop
   ↓
HashAggregate

Total Cost =
  Seq/Index Page Cost
+ CPU tuple cost
+ CPU operator cost
